描述
Bently Nevada 126599-01是一款专为航空衍生燃气轮机设计的振动监测I/O模块，属于3500/44M系统。以下是其产品详情：
基本信息
重量：约450g
尺寸：241.3mm×24.4mm×99.1mm
产地：美国
功能特点
输入输出配置：提供四个传感器输入和四个温度输入，传感器输入可支持2线和3线加速度计、速度传感器或近程传感器。每个温度输入都支持E、J、K和T型热电偶，以及双线或三线RTD。还具备六个继电器输出、四个4-20mA记录器输出和一个专用缓冲输出。
通信能力：支持通过以太网和软件可配置的RS232/485串行端口进行Modbus通信，Modbus网关选项允许监视器直接向任何Modbus客户端提供静态变量、状态、事件列表、时间和日期信息。
可配置性：用户可以使用1900组态软件创建配置文件，并通过内置的以太网连接将文件下载到监视器，从而定义监视器操作和Modbus网关寄存器映射。还支持可选的显示器/键盘，以查看频道信息或进行较小的配置更改。
高精度测量：采用24位ADC转换，具备可配置的比例因子和满量程范围，报警精度within 0.13%of the desired value，频率响应为direct signal 4Hz to 30,000Hz(-3dB)等。
应用领域：主要应用于航空衍生燃气轮机的振动监测，可与Velomitor传感器和加速度计连接，实现对燃气轮机振动状态的实时监测和数据分析，确保设备的运行安全和可靠性。
The Bently Nevada 126599-01 is a vibration monitoring I/O module designed for aero-derivative gas turbines and is part of the 3500/44M system.Product details are as follows:
Basic Information
Weight:Approximately 450g
Dimensions:241.3mm×24.4mm×99.1mm
Origin:USA
Features
Input and Output Configuration:Provides four sensor inputs and four temperature inputs.The sensor inputs support 2-wire and 3-wire accelerometers,velocity sensors,or proximity sensors.Each temperature input supports E,J,K,and T-type thermocouples,as well as 2-wire or 3-wire RTDs.Also provided are six relay outputs,four 4-20mA recorder outputs,and one dedicated buffered output.
Communications:Supports Modbus communication via Ethernet and a software-configurable RS232/485 serial port.A Modbus gateway option allows the monitor to directly provide static variables,status,event lists,and time and date information to any Modbus client.Configurability:Users can create configuration files using 1900 Configuration Software and download them to the monitor via the built-in Ethernet connection,defining monitor operation and Modbus gateway register mapping.An optional display/keyboard is also supported for viewing channel information or making minor configuration changes.
High-Precision Measurement:Utilizing a 24-bit ADC with configurable scale factors and full-scale ranges,the monitor offers alarm accuracy within 0.13%of the desired value and a direct signal frequency response of 4Hz to 30,000Hz(-3dB).
Applications:Primarily used for vibration monitoring in aero-derivative gas turbines,the monitor can be connected to Velomitor sensors and accelerometers to enable real-time monitoring and data analysis of gas turbine vibration conditions,ensuring safe and reliable operation.
