描述
B&R X20CP1484是一款高性能的CPU模块，适用于B&R X20系列工业控制系统。以下是其产品详情：
基本信息
B&R ID代码：0x23a5
产品类型：CPU模块
冷却方式：无风扇
尺寸：150mm×99mm×85mm
重量：约0.7kg
技术规格
处理器：Intel Celeron 266（兼容）
内存：32MB SDRAM，1MB SRAM
接口：1个RS232接口，1个以太网接口，1个Powerlink V1/V2接口，2个USB接口，1个X2X link接口
电源：CPU和X2X link电源输入电压为24VDC（-15%/+20%），最大输入电流2.2A，具有反极性保护功能；X2X link电源输出额定功率为7W；输入I/O电源电压为24VDC（-15%/+20%），需要线路保险丝（最大10A，慢熔）；输出I/O电源额定输出电压为24VDC，允许接触负载为10A。
功耗：无存储卡、接口模块和USB时为10.5W；X2X link和I/O电源的内部功耗，总线为1.42W，内部I/O为0.6W。
状态指示：具备CPU功能、过热、以太网、Powerlink、CompactFlash、电池等状态指示灯。
The B&R X20CP1484 is a high-performance CPU module suitable for the B&R X20 series industrial control systems.The following are product details:
Basic Information
B&R ID Code:0x23a5
Product Type:CPU Module
Cooling Method:Fanless
Dimensions:150mm×99mm×85mm
Weight:Approximately 0.7kg
Technical Specifications
Processor:Intel Celeron 266(compatible)
Memory:32MB SDRAM,1MB SRAM
Interfaces:1 RS232,1 Ethernet,1 Powerlink V1/V2,2 USB,1 X2X Link
Power Supply:The CPU and X2X Link power supply input voltage is 24VDC(-15%/+20%),with a maximum input current of 2.2A and reverse polarity protection.The X2X Link power supply output is rated at 7W.The input I/O power supply voltage is 24VDC(-15%/+20%)and requires a line fuse(maximum 10A,slow-blow).The output I/O power supply is rated at 24VDC(-15%/+20%).24VDC,permissible contact load 10A.
Power consumption:10.5W without a memory card,interface module,or USB;internal power consumption for the X2X link and I/O power supply,bus power consumption 1.42W,internal I/O power consumption 0.6W.
Status Indicators:Indicators for CPU function,overheating,Ethernet,PowerLink,CompactFlash,and battery status.
