描述
产品概述
型号800-5745-1是Cognex公司推出的In-Sight 3000系列机器视觉控制器，属于工业自动化领域的核心组件。该产品主要用于高精度图像处理、缺陷检测及生产线质量控制，适用于汽车制造、电子装配、包装等行业。
核心功能
高性能图像处理：
支持实时图像采集与分析，分辨率可达1280×1024像素，检测速度达60帧/秒。
内置PatMax®几何匹配算法，适用于复杂背景下的目标定位。
多协议通信：
集成以太网、RS-232接口，兼容Modbus/TCP、EtherNet/IP等工业协议，与PLC、HMI设备无缝对接。
灵活配置：
通过In-Sight Explorer软件编程，支持自定义检测逻辑和报警触发条件。
技术规格
参数规格
型号版本Rev C/Rev E（存在多个迭代）
处理器专用DSP芯片
内存512MB RAM（可扩展）
输入电压24VDC（±10%）
防护等级IP65（防尘防水）
工作温度0℃至50℃
Product Overview
Model 800-5745-1 is the In-Sight 3000 series machine vision controller launched by Cognex,which is a core component in the field of industrial automation.This product is mainly used for high-precision image processing,defect detection and production line quality control,and is suitable for industries such as automobile manufacturing,electronic assembly,and packaging.
Core functions
High-performance image processing:
Supports real-time image acquisition and analysis,with a resolution of up to 1280×1024 pixels and a detection speed of up to 60 frames per second.
Built-in PatMax®geometric matching algorithm,suitable for target positioning in complex backgrounds.
Multi-protocol communication:
Integrated Ethernet and RS-232 interfaces,compatible with industrial protocols such as Modbus/TCP and EtherNet/IP,and seamlessly connected with PLC and HMI devices.
Flexible configuration:
Programmed through In-Sight Explorer software,supports custom detection logic and alarm trigger conditions.
Technical specifications
Parameters Specifications
Model version Rev C/Rev E(several iterations exist)
Processor Dedicated DSP chip
Memory 512MB RAM(expandable)
Input voltage 24VDC(±10%)
Protection level IP65(dustproof and waterproof)
Operating temperature 0℃to 50℃
