描述
主要特性和规格（MX2B3系列典型值）
风扇类型：交流轴流风扇
系列：Muffin系列（以在高压系统中的强劲性能而闻名）
尺寸：约119.13 x 119.13 x 39.12毫米（4.72 x 4.72 x 1.5英寸）。这是设备冷却风扇的标准尺寸。
工作电压：通常为115 VAC（交流电）。Muffin系列可能有230 VAC版本，但MX2B30的通用参考电压为115V。
频率：50/60 Hz
风量：零静压下约105 CFM（立方英尺/分钟）或170-196 m³/h（立方米/小时）。
功耗：约15W至20W。
电流：约0.18 A至0.26 A。
额定转速：约2850-3100 RPM（每分钟转数）。
噪音水平：通常约为47-52 dBA。
轴承类型：通常使用滚珠轴承以延长使用寿命。某些型号可能使用滑动轴承。
结构：
文丘里管/框架：高品质镁合金压铸框架，通常带有ED涂层和黑色粉末涂层。
螺旋桨：由塑料制成，通常阻燃等级为UL 94V-0。
端接：通常配备0.120英寸宽的端子用于电气连接。
预期寿命：设计用于长时间连续工作，通常称其在40°C下可工作83,000小时。
环境等级：
工作温度：通常为-10°C至70°C。
存储温度：-40°C至85°C。
机构认证：通常具有UL、CUL和CE认证。
应用
Comair Rotron Muffin系列风扇因其紧凑的尺寸和可靠的性能而广泛应用于各种电子和工业环境中的通用冷却。常见应用包括：
电子外壳：冷却内部组件以防止过热。
控制面板：散发继电器、PLC和电源产生的热量。
网络设备：路由器、交换机和服务器。
工业机械：冷却自动化设备内的组件。
医疗设备：确保适当的热管理适用于敏感电子设备。
电源：冷却变压器和其他电源组件。
Key Features and Specifications(Typical for MX2B3 Series)
Fan Type:AC Axial Fan
Series:Muffin Series(known for robust performance in high-pressure systems)
Dimensions:Approximately 119.13 x 119.13 x 39.12 mm(4.72 x 4.72 x 1.5 inches).This is a standard size for equipment cooling fans.
Operating Voltage:Typically 115 VAC(Alternating Current).There might be 230 VAC variants in the Muffin series,but the common reference for MX2B30 points to 115V.
Frequency:50/60 Hz
Air Flow:Around 105 CFM(Cubic Feet per Minute)or 170-196 m³/h(Cubic Meters per Hour)at zero static pressure.
Power Consumption:Approximately 15W to 20W.
Current:Around 0.18 A to 0.26 A.
Nominal Speed:Approximately 2850-3100 RPM(Revolutions Per Minute).
Noise Level:Typically around 47-52 dBA.
Bearing Type:Often uses Ball Bearings for extended life.Some variants might use sleeve bearings.
Construction:
Venturi/Frame:High-quality magnesium alloy die-casting frame,often with ED coating and powder coating in black.
Propeller:Made of plastic,typically UL 94V-0 rated for flame retardancy.
Termination:Often comes with 0.120″wide terminals for electrical connection.
Life Expectancy:Designed for a long continuous duty life,often cited as 83,000 hours at 40°C.
Environmental Ratings:
Operating Temperature:Typically-10°C to 70°C.
Storage Temperature:-40°C to 85°C.
Agency Approvals:Usually carries UL,CUL,and CE approvals.
Applications
Comair Rotron Muffin series fans are popular for general-purpose cooling in various electronic and industrial settings due to their compact size and reliable performance.Common applications include:
Electronic Enclosures:Cooling internal components to prevent overheating.
Control Panels:Dissipating heat generated by relays,PLCs,and power supplies.
Networking Equipment:Routers,switches,and servers.
Industrial Machinery:Cooling components within automated equipment.
Medical Devices:Ensuring proper thermal management for sensitive electronics.
Power Supplies:Cooling transformers and other power components.
