描述
产品简要说明
CONVERTEAM MAE94-01是通用电气（GE Energy）旗下品牌CONVERTEAM设计的工业控制器模块，核心特性包括：
多功能集成：支持信号处理、通信协议转换及功率控制
工业级防护：IP65防护等级，适应高温、高湿环境
灵活扩展：兼容Converteam系列I/O模块与通信接口
产品详细说明
1.硬件架构与核心参数
物理特性
尺寸：推测为标准模块化设计（参考CONVERTEAM MVC3001-4003A）
重量：约1.2-1.5kg
安装方式：导轨式或面板安装
电气性能
输入电压：
DC 24V/48V（典型工业电压）
功耗：≤15W（满载）
通信接口：
2×CAN总线（支持CANopen协议）
1×EtherCAT工业以太网
信号处理能力
数字I/O：
支持扩展模块（如CONVERTEAM P110系列），最大支持256点I/O
模拟量输入：
4-20mA/0-10V通道，16位分辨率
产品概述:CONVERTEAM MAE94-01
作为工业自动化控制的核心组件，其核心价值在于高可靠性与行业深度适配：
技术优势：
冗余电源设计（双路DC输入）
温度自适应调节（-40°C至+70°C）
行业适配：
能源管理：风力发电机组功率调节
轨道交通：列车辅助系统控制
工业驱动：电机启停与转速控制
技术规格:CONVERTEAM MAE94-01
参数项规格描述
处理速度500指令/毫秒
存储容量256KB程序存储+64KB数据存储
通信协议CANopen、EtherCAT、Modbus TCP
工作温度-40°C至+70°C
防护等级IP65（防尘防水）
核心价值与性能亮点
1.多协议兼容性
技术支撑：
内置协议转换中间件，支持CANopen与EtherCAT无缝对接
案例：某风电场中，单模块协调50台变桨电机控制
2.能源效率优化
技术支撑：
动态功率调节算法，降低待机能耗30%
案例：工业泵站中，年节电成本节省15%
smart
smart
Product brief description
CONVERTEAM MAE94-01 is an industrial controller module designed by CONVERTEAM,a brand under GE Energy.The core features include:
Multifunctional integration:supports signal processing,communication protocol conversion and power control
Industrial protection:IP65 protection level,adapted to high temperature and high humidity environments
Flexible expansion:compatible with Converteam series I/O modules and communication interfaces
Product details
1.Hardware architecture and core parameters
Physical characteristics
Dimension:Presumably a standard modular design(see CONVERTEAM MVC3001-4003A)
Weight:about 1.2-1.5kg
Installation method:rail type or panel installation
Electrical performance
Input voltage:
DC 24V/48V(typical industrial voltage)
Power consumption:≤15W(full load)
Communication interface:
2×CAN bus(supports CANopen protocol)
1×EtherCAT Industrial Ethernet
Signal processing capability
Digital I/O:
Supports expansion modules(such as CONVERTEAM P110 series),with a maximum support of 256 points I/O
Analog input:
4-20mA/0-10V channel,16-bit resolution
Product Overview:CONVERTEAM MAE94-01
As the core component of industrial automation control,its core value lies in high reliability and deep adaptation of industry:
Technical Advantages:
Redundant power supply design(dual DC input)
Temperature adaptive adjustment(-40°C to+70°C)
Industry adaptation:
Energy Management:Power Regulation of Wind Generators
Rail Transit:Train Assisted System Control
Industrial Drive:Motor Start and Stop and SpeedControl
Technical Specifications:CONVERTEAM MAE94-01
Parameters Specification Description
Processing speed 500 instructions/ms
Storage capacity:256KB program storage+64KB data storage
Communication Protocols CANopen,EtherCAT,Modbus TCP
Operating temperature-40°C to+70°C
Protection level IP65(dust-proof and waterproof)
Core Valuesand Performance Highlights
1.Multi-protocol compatibility
Technical support:
Built-in protocol conversion middleware,supports seamless connection between CANopen and EtherCAT
Case:In a wind farm,a single module coordinates the control of 50 pitch motors
2.Energy efficiency optimization
Technical support:
Dynamic power regulation algorithm reduces standby energy consumption by 30%
Case:In industrial pump stations,annual power saving cost savings 15%
