描述
主要产品详情及功能
工业级隔离RS-232收发器：该模块充当转换器，将来自计算机或控制器的标准RS-232串行信号转换为隔离信号。“隔离”特性对于工业环境至关重要，因为它采用了光耦合隔离技术。这有效地隔离了连接设备的数字地，防止共模干扰和电气噪声影响数据传输。
增强的抗干扰能力：专为在恶劣的工业环境中稳定运行而设计，具有强大的抗电磁干扰(EMI)和电磁兼容性(EMC)能力，符合行业对稳健通信的标准。
多重保护功能：为确保可靠的数据传输并保护连接的设备，它集成了多种保护功能：
过压保护：防止破坏性的浪涌电压。
过流保护：防止过大电流造成的损坏。
静电保护：防止静电放电损坏敏感的电子元件。
逻辑运算支持：除了简单的信号转换外，该模块还支持逻辑运算。这意味着它可以执行布尔运算、数据传输和逻辑比较。这增加了一层智能，使其能够直接在通信接口处理输入信号，以执行生产线状态判断或传感器信号处理等任务。
低功耗：其功耗通常低于100 mW，节能高效，适用于注重电源效率的应用，甚至可能是电池供电的系统。
紧凑尺寸：其紧凑的设计使其易于集成到空间有限的现有工业系统和控制柜中。
通用规格
型号：ICP232.2-5V 029.361114
接口类型：RS-232
供电电压：5V DC±10%
功耗：<100 mW
工作温度范围：-20°C至+70°C
抗干扰能力：EMI/EMC符合行业标准
隔离类型：光耦隔离技术
典型应用
DATEL ICP232.2-5V 029.361114在需要可靠、稳定的RS-232通信的各种工业和技术领域中至关重要：
工业自动化：
连接PLC（可编程逻辑控制器）、变频器和人机界面(HMI)等工业设备，实现复杂的逻辑控制，例如判断生产线状态或处理传感器信号。
数据采集：
从传感器收集数据，并将其可靠地传输到上级计算机或数据记录系统进行分析和存储。
测试与测量：
用于与实验室或工业测试环境中的仪器和测试设备进行串行通信。
医疗设备：
连接医疗设备以传输患者数据或控制诊断设备。
嵌入式系统：
集成到微控制器或单板计算机中，为小型设备提供逻辑处理能力，执行调度或状态确定等任务。
Key Product Details and Functions
Industrial-Grade Isolated RS-232 Transceiver:This module acts as a converter,transforming standard RS-232 serial signals from computers or controllers into isolated signals.The”isolated”aspect is crucial for industrial settings,as it uses optical coupling isolation technology.This effectively isolates the digital ground of the connected devices,preventing common-mode interference and electrical noise from affecting data transmission.
Enhanced Anti-Interference Capability:Designed to operate stably in harsh industrial environments,it offers strong resistance to electromagnetic interference(EMI)and electromagnetic compatibility(EMC),meeting industry standards for robust communication.
Multiple Protection Features:To ensure reliable data transmission and protect connected equipment,it incorporates various protection functions:
Overvoltage Protection:Guards against damaging voltage surges.
Overcurrent Protection:Prevents damage from excessive current flow.
Electrostatic Protection:Protects against electrostatic discharge,which can damage sensitive electronic components.
Logic Operation Support:Beyond simple signal conversion,this module supports logical operations.This means it can perform Boolean operations,data transfer,and logical comparisons.This adds a layer of intelligence,allowing it to process input signals for tasks like production line status judgment or sensor signal processing directly at the communication interface.
Low Power Consumption:With a power consumption of typically less than 100 mW,it’s energy-efficient and suitable for applications where power efficiency is important,potentially even battery-powered systems.
Compact Size:Its compact design facilitates easy integration into existing industrial systems and control cabinets where space might be limited.
General Specifications
Model:ICP232.2-5V 029.361114
Interface Type:RS-232
Supply Voltage:5V DC±10%
Power Consumption:<100 mW
Operating Temperature Range:-20°C to+70°C
Anti-interference Capability:EMI/EMC compliant with industry standards
Isolation Type:Optical coupling isolation technology
Typical Applications
The DATEL ICP232.2-5V 029.361114 is vital in various industrial and technical fields where reliable and robust RS-232 communication is required:
Industrial Automation:
Connecting industrial equipment like PLCs(Programmable Logic Controllers),inverters,and human-machine interfaces(HMIs)for complex logic control,such as judging production line status or processing sensor signals.
Data Acquisition:
Collecting data from sensors and transmitting it reliably to higher-level computers or data logging systems for analysis and storage.
Test and Measurement:
Used for serial communication with instruments and test equipment in laboratory or industrial testing setups.
Medical Devices:
Connecting medical devices to transfer patient data or control diagnostic equipment.
Embedded Systems:
Integrated into microcontrollers or single-board computers to provide logic processing power for small devices,handling tasks like scheduling or condition determination.
