描述
产品简要说明
INWATT 16180-1是DEIF开发的高性能双向直流逆变器，专为可再生能源系统与储能设备设计。其核心特性包括：
宽电压输入范围：适应光伏/储能系统波动
动态效率优化：基于负载的实时能效调节
孤岛保护：符合IEEE 1547标准的主动检测机制
产品详细说明
1.拓扑结构与转换机制
电路设计创新
三电平NPC拓扑：
降低开关损耗（效率提升至97.8% 满载）
软开关技术：
零电压开通（ZVS）减少EMI干扰
动态响应特性
瞬态调节：
负载阶跃变化时响应时间<5ms
谐波抑制：
输出THD<3%（满足IEC 61000-4-7）
2.智能控制体系
核心算法
MPPT优化：
自适应扰动观察法（扫描步长可调0.1-2V）
SoC协同管理：
与BMS系统联动（CANopen协议）
安全防护矩阵
过压保护：
DC 1200V耐受（creepage distance 8mm）
热失控预防：
液冷散热选项（ΔT<15°C 90%负载）
3.**系统集成能力
通信协议栈
工业总线：
Profinet+EtherCAT双协议支持
云接口：
MQTT协议远程监控（TLS 1.3加密）
扩展架构
模块化设计：
最大支持4单元并联（N+1冗余）
混合组网：
兼容Siemens S7-1500系列PLC
Product brief description
INWATT 16180-1 is a high-performance bidirectional DC inverter developed by DEIF,designed for renewable energy systems and energy storage equipment.Its core features include:
Wide voltage input range:adapt to fluctuations in photovoltaic/energy storage systems
Dynamic efficiency optimization:real-time energy efficiency regulation based on load
Island protection:Active detection mechanism that complies with IEEE 1547 standards
Product details
1.Topology structure and transformation mechanism
Circuit design innovation
Three-level NPC topology:
Reduce switching losses(efficiency increased to 97.8%full load)
Soft switch technology:
Zero voltage ON(ZVS)reduces EMI interference
Dynamic response characteristics
Transient adjustment:
Response time during load step change<5ms
Harmonic Suppression:
Output THD<3%(meets IEC 61000-4-7)
2.Intelligent control system
Core algorithm
MPPT optimization:
Adaptive perturbation observation method(scan step size can be adjusted by 0.1-2V)
SoC collaborative management:
Linkage with BMS system(CANopen protocol)
Security protection matrix
Overvoltage protection:
DC 1200V tolerant(creepage distance 8mm)
Thermal runaway prevention:
Liquid-cooled cooling options(ΔT<15°C 90%load)
3.**System integration capability
Communication protocol stack
Industrial bus:
Profinet+EtherCAT dual protocol support
Cloud interface:
MQTT protocol remote monitoring(TLS 1.3 encryption)
Extended architecture
Modular design:
Supports up to 4 units parallel connection(N+1 redundancy)
Hybrid networking:
Compatible with Siemens S7-1500 series PLC
