描述
产品简要说明
SCM-1是DEIF专为船舶电力系统设计的可编程控制模块，核心特性包括：
模块化架构：由SCM-A主控板与两块功能扩展板组成
通信灵活：支持八线总线与背板总线双模式
工业级可靠性：通过DNV船级社认证，工作温度范围-20°C～+60°C
产品详细说明
1.硬件架构与功能集成
模块组成
SCM-A主控板：
集成32位工业级MCU，负责逻辑运算与协议解析
扩展模块：
可选配继电器输出板（8路）或模拟量采集板（4通道隔离）
通信协议栈
支持Modbus TCP/IP、CAN 2.0B及NMEA 2000协议，实现与船舶DCS系统的无缝集成
2.软件特性与编程接口
开发环境功能描述
DEIF Configurator可视化逻辑编辑器，支持ladder diagram编程
产品概述:SCM-1
作为DEIF船舶自动化系统的关键组件，SCM-1通过模块化设计实现设备状态监测、逻辑控制与数据转发，特别适用于发电机并车、负载均衡等复杂场景。
技术规格:SCM-1
参数类别技术指标
输入电压110～230V AC（宽范围适应）
功耗典型值≤15W（满载）
防护等级|IP20（机柜安装型）/IP65（面板密封选配）|
核心价值与性能亮点
1.船舶场景适配
案例验证：
某集装箱船应用中，实现主发电机自动并网控制（响应时间<200ms）
2.故障容错设计
双总线冗余：
八线总线故障时自动切换至背板总线（切换时间<50ms）
应对挑战，创造价值
1.极端环境验证
高湿度测试：
在95%RH环境下连续运行1000小时无性能衰减
2.电磁兼容性
IEC 61000-4-2：
抗静电放电等级±8kV（接触放电）
客户关注的焦点
兼容性扩展：
支持与PPU 2GS保护继电器的联动控制
诊断可视化：
前面板LED指示灯显示八种故障状态（包括通信中断、过载等）
Product brief description
SCM-1 is a programmable control module designed by DEIF for marine power systems.The core features include:
Modular architecture:consists of SCM-A main control board and two functional expansion boards
Flexible communication:supports dual modes of eight-wire bus and backplane bus
Industrial-grade reliability:passed DNV classification society certification,working temperature range-20°C~+60°C
Product details
1.Hardware architecture and function integration
Module composition
SCM-A main control board:
Integrated 32-bit industrial-grade MCU,responsible for logical operations and protocol analysis
Extension module:
Optional relay output board(8 channels)or analog quantity acquisition board(4 channels isolation)
Communication protocol stack
Supports Modbus TCP/IP,CAN 2.0B and NMEA 2000 protocols to achieve seamless integration with marine DCS systems
2.Software features and programming interfaces
Development Environment Function Description
DEIF Configurator Visual Logic Editor,Supports Ladder Diagram Programming
Product Overview:SCM-1
As a key component of DEIF’s ship automation system,SCM-1 realizes equipment status monitoring,logic control and data forwarding through modular design,which is especially suitable for complex scenarios such as generator convergence and load balancing.
Technical Specifications:SCM-1
Parameter category Technical indicators
Input voltage 110~230V AC(wide range adaptation)
Power consumption Typical value≤15W(full load)
Protection level|IP20(cabinet installation type)/IP65(optional panel sealing)|
Core Valuesand Performance Highlights
1.Ship scene adaptation
Case verification:
In a container ship application,the main generator is automatically connected to the grid(response time<200ms)
2.Fault fault tolerance design
Dual bus redundancy:
Automatically switch to the backplane bus when the eight-wire bus fails(switching time<50ms)
Respond to challenges and create value
1.Extreme environment verification
High humidity test:
No performance degradation when running continuously for 1000 hours in 95%RH environment
2.Electromagnetic compatibility
IEC 61000-4-2:
Antistatic discharge level±8kV(contact discharge)
Customer focus
Compatibility Extensions:
Supports linkage control with PPU 2GS protection relay
Diagnostic visualization:
The front panel LED indicator light shows eight fault statuses(including communication interruption,overload,etc.)
