SCM-A是DEIF面向船舶电力系统开发的高性能主控模块，核心特性包括：
混合信号处理：6路隔离数字输入+4路高精度模拟输出
协议兼容性：支持CANopen DS301与Modbus TCP/IP双协议
环境适应性：IP66防护+宽温工作（-25°C～+70°C）
产品详细说明
1.硬件架构与功能集成
输入输出配置
数字输入：
光电隔离（3000Vrms），支持船用无源触点信号采集，响应时间<10ms
模拟输出：
16位D/A转换器，支持0-10V/4-20mA自由配置（负载能力≥1kΩ）
通信接口
CANopen：
符合DS301标准，支持PDO/RPDO实时数据传输
以太网：
10/100M自适应端口，支持远程固件升级
2.软件特性与扩展性
功能模块技术参数
逻辑控制支持ladder diagram编程（兼容IEC 61131-3标准）
数据存储|内置TF卡插槽（最大支持32GB），可记录1年历史报警数据|
产品概述:SCM-A 1044220110F
作为DEIF船舶自动化系统的核心控制单元，SCM-A通过模块化设计实现设备状态监测、逻辑控制与数据转发，特别适用于发电机并网、负载均衡等高可靠性要求场景。
技术规格:SCM-A 1044220110F
参数类别技术指标
电源24V DC（±25%波动容限）
功耗待机5W/满载12W
安装方式|DIN导轨+防水接线端子（符合IEC 61076）
核心价值与性能亮点
1.船舶场景适配
案例验证：
某LNG运输船应用中，实现主发电机自动并网控制（同步精度±0.5°）
2.故障容错设计
双通道通信：
CANopen与以太网数据同步传输，故障切换时间≤30ms
应对挑战，创造价值
1.极端环境验证
盐雾测试：
通过ISO 12944标准（500小时无腐蚀）
2.电磁兼容性
IEC 6100onymous：
抗脉冲群干扰等级4级（电源端口2kV）
客户关注的焦点
配置效率：
推荐使用DEIF Navigator软件实现参数批量下发（支持CSV导入）
维护成本：
模块平均无故障时间>15万小时（MTBF）
Product brief description
SCM-A is a high-performance main control module developed by DEIF for marine power systems.The core features include:
Mixed signal processing:6-channel isolated digital input+4-channel high-precision analog output
Protocol compatibility:Supports CANopen DS301 and Modbus TCP/IP dual protocols
Environmental adaptability:IP66 protection+wide temperature operation(-25°C~+70°C)
Product details
1.Hardware architecture and function integration
Input and output configuration
Digital input:
Optoelectronic isolation(3000Vrms),supports marine passive contact signal acquisition,response time<10ms
Analog output:
16-bit D/A converter,supports free configuration of 0-10V/4-20mA(load capacity≥1kΩ)
Communication interface
CANopen:
Comply with DS301 standard and supports PDO/RPDO real-time data transmission
Ethernet:
10/100M adaptive port,supports remote firmware upgrade
2.Software features and scalability
Functional module Technical parameters
Logic control supports ladder diagram programming(compatible with IEC 61131-3 standard)
Data storage|Built-in TF card slot(maximum support 32GB),can record 1 year of historical alarm data|
Product Overview:SCM-A 1044220110F
As the core control unit of DEIF ship automation system,SCM-A realizes equipment status monitoring,logic control and data forwarding through modular design,and is especially suitable for high-reliability requirements such as generator grid connection and load balancing.
Technical Specifications:SCM-A 1044220110F
Parameter category Technical indicators
Power supply 24V DC(±25%fluctuation tolerance)
Power consumption:5W standby/12W full load
Installation method|DIN rail+waterproof terminal(compliant with IEC 61076)
Core Valuesand Performance Highlights
1.Ship scene adaptation
Case verification:
In the application of a certain LNG transport ship,the main generator is automatically connected to the grid(synchronization accuracy±0.5°)
2.Fault fault tolerance design
Dual channel communication:
CANopen and Ethernet data are transmitted simultaneously,and the failover time is≤30ms
Respond to challenges and create value
1.Extreme environment verification
Salt spray test:
Passed ISO 12944 standard(500 hours of corrosion-free)
2.Electromagnetic compatibility
IEC 6100onymous:
Anti-pulse group interference level 4(power port 2kV)
Customer focus
Configuration efficiency:
It is recommended to use DEIF Navigator software to implement batch distribution of parameters(support CSV import)
Maintenance cost:
Average module failure-free time>150,000 hours(MTBF)
