描述
产品简要说明
TMF-210DG2是DEIF专为工业与船舶环境设计的多功能温度监测模块，支持热电阻（Pt100/Pt1000）与热电偶（K/J型）双模式输入，具备以下核心能力：
高精度测量：±0.2℃（全量程）
恶劣环境适应：IP65防护+抗震等级3g
智能报警：超限、断线、传感器故障三重预警
产品详细说明
1.温度监测核心功能
输入通道配置：
6个独立通道可独立设置传感器类型（热电阻/热电偶）及测量范围（-200°C–1200°C）
信号处理技术：
24位ADC采样+数字滤波算法，抑制电磁干扰（抗噪能力≥85dB 50Hz）
2.报警与联动控制
报警类型触发条件与响应方式
超温报警阈值可设（步进0.1℃），触发光耦隔离输出
断线检测开路/短路自动识别，状态上传至PLC
传感器故障内部诊断覆盖接线错误、元件老化
联动场景示例
某液化气船应用中，TMF-210DG2与PPMSG SYSTEM-2联动，实现货舱温度异常时自动切换冷却泵。
产品概述:TMF-210DG2
作为DEIF环境监测体系的关键组件，TMF-210DG2通过模块化设计与高可靠性架构，满足船舶引擎室、工业反应釜等场景的分布式温度监控需求，符合DNV-GL船级社认证标准。
技术规格:TMF-210DG2
参数类别技术指标
输入类型热电阻（Pt100/Pt1000）/热电偶（K/J/E/T型）
测量精度±0.2℃（热电阻），±1℃（热电偶） 25°C基准
Product brief description
TMF-210DG2 is a multifunctional temperature monitoring module designed by DEIF for industrial and marine environments.It supports dual-mode input of thermal resistor(Pt100/Pt1000)and thermocouple(K/J type),and has the following core capabilities:
High-precision measurement:±0.2℃(full range)
Harsh environment adaptation:IP65 protection+earthquake resistance level 3g
Intelligent alarm:triple warning of over-limit,disconnection,sensor failure
Product details
1.Core function of temperature monitoring
Input channel configuration:
6 independent channels can independently set the sensor type(thermal resistance/thermocouple)and the measurement range(-200°C–1200°C)
Signal processing technology:
24-bit ADC sampling+digital filtering algorithm to suppress electromagnetic interference(noise resistance≥85dB 50Hz)
2.Alarm and linkage control
Alarm type Trigger condition and response method
Overtemperature alarm The threshold can be set(stepped 0.1℃),triggering the optical coupling isolation output
Disconnection detection Open circuit/short circuit automatic identification,status uploaded to PLC
Sensor failure Internal diagnostic coverage wiring errors,component aging
Linkage scenario example
In a certain liquefied gas ship application,TMF-210DG2 is linked to PPMSG SYSTEM-2 to automatically switch the cooling pump when the cargo hold temperature is abnormal.
Product Overview:TMF-210DG2
As a key component of the DEIF environmental monitoring system,TMF-210DG2 meets the distributed temperature monitoring needs of ship engine rooms,industrial reactors and other scenarios through modular design and high reliability architecture,and complies with the DNV-GL classification society certification standards.
Technical specifications:TMF-210DG2
Parameter category Technical indicators
Input type Thermal resistance(Pt100/Pt1000)/Thermocouple(K/J/E/T type)
Measurement accuracy±0.2℃(thermal resistance),±1℃(thermocouple) 25°C reference
