描述
主要产品详情及功能
接口板模块：DSPU131的主要作用是作为接口，连接控制系统的各个部分。它通常被称为“MA200接口板”。
AT总线兼容性：该板卡设计用于兼容AT总线，AT总线是ABB老一代Advant OCS（开放式控制系统）平台常用的通信总线。这确保了这些系统内的无缝集成和数据流。
处理器：它通常包含一个32位DSP（数字信号处理器）芯片，主频高达200 MHz。这种处理能力使其能够处理复杂的通信协议和数据处理任务。
工程师站模块作用：DSPU131 3BSE000355R1可用作Advant OCS系统中的工程师站模块。在此角色中，它负责：
定义和维护设备参数：在继电保护工程师系统中存储有关设备及其相关数据点的信息。
下载配置文件和算法模块：将编译好的控制逻辑和配置数据发送到现场控制站。
离线配置和在线监控：允许工程师离线配置DCS系统，并在运行过程中对其进行监控、控制和维护，而不会影响过程控制。
编译算法：将控制算法模块编译为可执行文件（如DLL），并以XML文件的形式生成配置信息，详细说明硬件层次结构、接口参数和算法设置。
系统安全性和可靠性：通过访问控制、数据加密和日志记录来提高系统安全性，并提供维护和诊断工具。
通信和数据交换：它是Advant Master系统中各种输入/输出(I/O)模块、通信模块和其他组件之间进行通信和数据交换的关键连接点。
坚固的工业设计：与其他ABB工业组件一样，它旨在在严苛的工业环境中可靠运行，并考虑了电磁干扰(EMI)和正确的接地。
技术规格（通用）
产品编号：3BSE000355R1
型号：DSPU131（有时也称为DSPU 131 MA200）
产品类型：接口板/控制系统附件
处理器：32位DSP，最高200 MHz
尺寸（大约）：
长度：334.6毫米
高度：121.9毫米
宽度：21毫米
重量（大约）：0.42千克（或约1千克，含运输重量）
原产国：瑞典或瑞士
RoHS豁免：此部件通常不受2011/65/EU(RoHS)法规的约束。
WEEE类别：归类为WEEE第5类（小型设备，外部尺寸不超过50厘米）。
典型应用
ABB DSPU131 3BSE000355R1广泛应用于采用ABB Advant Master过程控制系统的行业，包括：
工业自动化：各种自动化过程的控制和通信核心。
电力系统：用于变电站和发电厂的继电保护工程系统。
石油化工行业：支持关键过程控制和管理。
其他过程工业：部署Advant OCS进行全面控制和数据处理的所有领域。
Key Product Details and Functions
Interface Board Module:The primary role of the DSPU131 is to serve as an interface,connecting different parts of a control system.It’s often specifically referred to as an”MA200 Interface Board.”
AT-bus Compatibility:This board is designed for compatibility with the AT-bus,a communication bus commonly used in ABB’s older generation Advant OCS(Open Control System)platforms.This ensures seamless integration and data flow within these systems.
Processor:It typically incorporates a 32-bit DSP(Digital Signal Processor)chip with a main frequency of up to 200 MHz.This processing power enables it to handle complex communication protocols and data processing tasks.
Engineering Station Module Role:The DSPU131 3BSE000355R1 can function as an engineering station module in Advant OCS systems.In this capacity,it is responsible for:
Defining and maintaining device parameters:Storing information about devices and their associated data points within the relay protection engineer system.
Downloading configuration files and algorithm modules:Sending compiled control logic and configuration data to on-site control stations.
Offline configuration and online supervision:Allowing engineers to configure the DCS system offline and then monitor,control,and maintain it during operation without impacting process control.
Compiling algorithms:Compiling control algorithm modules into executable files(like DLLs)and generating configuration information in XML files,detailing hardware hierarchy,interface parameters,and algorithm settings.
System security and reliability:Contributing to system security through access control,data encryption,and logging,and providing maintenance and diagnostic tools.
Communication and Data Exchange:It’s a key connection point that enables communication and data exchange between various input/output(I/O)modules,communication modules,and other components in the Advant Master system.
Robust Industrial Design:Like other ABB industrial components,it’s built to operate reliably in demanding industrial environments,with considerations for electromagnetic interference(EMI)and proper grounding.
Technical Specifications(General)
Product ID:3BSE000355R1
Type Designation:DSPU131(sometimes also referred to as DSPU 131 MA200)
Product Type:Interface Board/Control System Accessory
Processor:32-bit DSP,up to 200 MHz
Dimensions(approximate):
Length:334.6 mm
Height:121.9 mm
Width:21 mm
Weight(approximate):0.42 kg(or around 1 kg for shipping)
Country of Origin:Sweden or Switzerland
RoHS Exemption:This part is typically exempted from the scope of 2011/65/EU(RoHS)regulations.
WEEE Category:Classified as WEEE Category 5(Small Equipment,No External Dimension More Than 50 cm).
Typical Applications
The ABB DSPU131 3BSE000355R1 is widely utilized in sectors that employ ABB’s Advant Master process control systems,including:
Industrial Automation:Core to the control and communication backbone of various automated processes.
Power Systems:Used in substations and power plants for relay protection engineering systems.
Petrochemical Industry:Supporting critical process control and management.
Other Process Industries:Wherever the Advant OCS is deployed for comprehensive control and data handling.
