描述
产品简要说明
Eaton IDT 40-10300-03是伊顿(Eaton)IDT系列的智能低压空气断路器,专为商业建筑和工业配电系统设计。其核心功能包括:
保护等级:支持过载保护、短路保护及电弧故障检测(AFCI)
额定参数:40A三相(400V AC)
智能特性:内置故障诊断与通信接口
产品详细说明
1.硬件架构与核心功能
保护机制
电弧故障保护(AFCI):
实时监测电弧能量,响应时间≤50ms
适用场景:防止电缆老化引发的电气火灾
过载保护:
可调脱扣曲线(A型至D型)
支持分级保护配置
短路保护:
瞬时脱扣电流范围:10-40kA
通信接口
主通信端口:Modbus RTU(RS-485)
辅助接口:
1个Eaton Power Xpert诊断端口
安装与防护
安装方式:导轨式(DIN 35mm)
防护等级:IP20(室内环境适用)
抗振动标准:IEC 60068-2-6(10-55Hz,1.5mm振幅)
产品概述:Eaton IDT 40-10300-03
作为IDT系列的智能配电核心组件,其核心价值在于电气安全与系统可靠性:
技术优势:
AFCI技术:减少90%以上电弧故障风险(UL 1699标准)
模块化设计:支持扩展插件(如电能计量模块)
行业适配:
商业建筑:数据中心服务器机房配电
工业设施:工厂生产线电机控制柜
新能源领域:光伏逆变器并网保护
Product brief description
Eaton IDT 40-10300-03 is an Eaton IDT series of smart low-voltage air circuit breakers designed for commercial construction and industrial distribution systems.Its core functions include:
Protection level:Support overload protection,short circuit protection and arc fault detection(AFCI)
Rated parameters:40A three-phase(400V AC)
Intelligent features:built-in fault diagnosis and communication interface
Product details
1.Hardware architecture and core functions
Protection mechanism
Arc Fault Protection(AFCI):
Real-time monitoring of arc energy,response time≤50ms
Applicable scenarios:Prevent electrical fires caused by cable aging
Overload protection:
Adjustable tripping curve(type A to type D)
Supports hierarchical protection configuration
Short circuit protection:
Instantaneous trip current range:10-40kA
Communication interface
Main communication port:Modbus RTU(RS-485)
Auxiliary interface:
1 Eaton Power Xpert diagnostic port
Installation and protection
Installation method:rail type(DIN 35mm)
Protection level:IP20(applicable in indoor environment)
Vibration resistance standard:IEC 60068-2-6(10-55Hz,1.5mm amplitude)
Product Overview:Eaton IDT 40-10300-03
As the core component of the IDT series of intelligent power distribution,its core value lies in electrical safety and system reliability:
Technical Advantages:
AFCI technology:Reduce arc fault risk by more than 90%(UL 1699 standard)
Modular design:Supports extension plug-ins(such as power metering modules)
Industry adaptation:
Commercial building:Data center server room power distribution
Industrial facilities:Factory production line motor control cabinet
New energy field:photovoltaic inverter grid-connected protection
