描述
Eaton（伊顿）MDS-832是一款工业级无线调制解调器（Modem），属于其MDS™Orion系列，专为工业自动化、SCADA（数据采集与监控）系统、电力、石油天然气、水处理等严苛环境设计。以下是该产品的核心详情：
一、产品概述
型号：MDS-832
类型：工业无线调制解调器（支持点对点、点对多点通信）
应用场景：远程数据传输、设备监控、自动化控制网络、无线传感器网络等。
二、核心功能与特性
多频段支持
支持900MHz、2.4GHz、5.8GHz等频段，适应不同地区频谱法规。
可选跳频扩频（FHSS）或直接序列扩频（DSSS）技术，增强抗干扰能力。
高速数据传输
最高传输速率可达230.4 Kbps（具体速率取决于频段和配置）。
支持透明传输或协议封装（如Modbus、DNP3等工业协议）。
工业级设计
防护等级：IP67（防尘防水），适应恶劣环境。
工作温度：-40°C至+75°C，适合极端气候。
抗振动/冲击：符合IEC 60068-2标准，适合移动或振动场景。
安全与可靠性
AES-128/256加密：保障数据传输安全。
冗余通信：支持主备链路切换，提高网络可用性。
自愈网络：自动路由优化，适应节点故障或拓扑变化。
灵活配置
支持串口（RS-232/RS-485）和以太网接口，兼容多种设备。
可通过Web界面、SNMP、Telnet进行远程管理。
三、技术参数
参数详情
频段900MHz/2.4GHz/5.8GHz（可选）
调制方式FSK、QPSK、16-QAM等
传输距离视距条件下可达40+公里
输入电压10-30 VDC（支持PoE供电）
天线接口N型（可外接高增益天线）
认证FCC、CE、IC、ATEX（防爆认证可选）
The Eaton MDS-832 is an industrial-grade wireless modem from the Eaton MDS™Orion series,designed for harsh environments such as industrial automation,SCADA(Supervisory Control and Data Acquisition)systems,power generation,oil and gas,and water treatment.The following are key product details:
I.Product Overview
Model:MDS-832
Type:Industrial wireless modem(supports point-to-point and point-to-multipoint communication)
Applications:Remote data transmission,equipment monitoring,automation control networks,wireless sensor networks,etc.
II.Core Functions and Features
Multiple Frequency Band Support
Supports 900MHz,2.4GHz,and 5.8GHz frequency bands to adapt to different regional spectrum regulations.
Optional Frequency Hopping Spread Spectrum(FHSS)or Direct Sequence Spread Spectrum(DSSS)technology enhances interference resistance.
High-SpeedData Transmission
Maximum transmission rate reaches 230.4 Kbps(specific rate depends on frequency band and configuration).
Supports transparent transmission or protocol encapsulation(such as Modbus,DNP3,and other industrial protocols).Industrial-grade design
IP67 protection rating(dust and water resistant),suitable for harsh environments.
Operating temperature:-40°C to+75°C,suitable for extreme climates.
Vibration/shock resistance:Compliant with IEC 60068-2,suitable for mobile and vibrating environments.
Security and reliability
AES-128/256 encryption:Ensures data transmission security.
Redundant communication:Supports active/standby link switchover to improve network availability.
Self-healing network:Automatically optimizes routing to adapt to node failures or topology changes.
Flexible configuration
Supports serial ports(RS-232/RS-485)and Ethernet interfaces,compatible with a wide range of devices.
Remote management via a web interface,SNMP,and Telnet.III.Technical Specifications
Parameter Details
Frequency Band:900MHz/2.4GHz/5.8GHz(optional)
Modulation:FSK,QPSK,16-QAM,etc.
Transmission Distance:Up to 40+km in line-of-sight conditions
Input Voltage:10-30 VDC(supports PoE)
Antenna Interface:N-Type(supports external high-gain antennas)
Certifications:FCC,CE,IC,ATEX(explosion-proof certification optional)
