描述
主要产品详情和功能
财务计量和贸易交接：FloBoss S600的主要用途是为碳氢化合物的财务（商业）交易和贸易交接进行高精度测量。这意味着它适用于流体输送量直接影响财务协议的情况。
多流路、多站功能：S600能够处理复杂的配置。它允许同时计量多个流路（使用扩展模块最多可达10个）和多个站（最多可达2个）的液体和气体。这使得它能够灵活地满足各种测量需求。
高精度计算：所有计量计算均使用64位（双精度）浮点数进行，以实现最高精度。累计总数存储在三个独立的内存位置（Tri-reg格式），以确保最高的数据完整性并防止数据丢失。
支持广泛的测量标准：FloBoss S600兼容多种全球气体和液体测量标准，包括：
气体：AGA、ISO、GPA、GERG、GOST
液体：API、ASTM、GPA、NORSOK
分布式处理：S600采用分布式处理技术，以实现最佳性能。主CPU集成硬件浮点处理器，每个附加I/O卡也拥有各自的本地处理能力。这种架构减轻了主CPU的任务负担，从而提高了系统整体效率和响应速度。
多种通信接口：提供强大的连接选项，可集成到各种控制系统中：
以太网（S600+最多两个端口）：支持Modbus/TCP和Modbus over以太网。S600+型号通常标配两个100Mb/s全双工以太网端口。
串行端口：多个可配置的EIA-232(RS-232)和EIA-422/EIA-485串行端口。
HART：可选配P188.R2模块，支持智能现场设备的HART通信，提供高级诊断和远程配置功能。
USB端口：S600+后置USB端口，可用于将报告下载到闪存盘。
嵌入式Web服务器(S600+)：S600+内置Web服务器，支持远程访问和管理，从而提高运营效率并简化维护。
仪表校准应用：支持各种仪表校准方法，包括紧凑型、单向型、双向型、主表型和双计时型，并支持1、2或4个球形开关。每个S600最多可支持两个校准仪。
LogiCalc™用户语言：它采用LogiCalc™用户语言，这是一种功能强大、用户友好的语言，支持自定义配置和双精度数学函数。
本地显示屏和键盘：该设备配备显示屏和键盘，操作员无需单独的PC即可直接在现场查看或修改系统参数。
坚固可靠的设计：FloBoss S600专为严苛的工业环境而设计，确保高可靠性和长校准周期，从而有助于降低维护成本。
FloBoss S600+(Plus)增强功能
FloBoss S600+是S600的升级版，在其成功的基础上进行了多项关键改进：
重新设计的CPU：融合最新技术进步，性能更佳。
增强的通信功能：标配两个以太网端口（之前为一个标准端口，一个可选端口）和更多串行端口。
扩展数据记录功能：改进的数据记录功能。
向后兼容：完全向后兼容现有的S600安装。
更快的配置下载：配置下载时间显著加快（约快10倍）。
Key Product Details and Functions
Fiscal Measurement and Custody Transfer:The primary purpose of the FloBoss S600 is to perform highly accurate measurements for fiscal(commercial)transactions and custody transfer of hydrocarbons.This means it’s used where the quantity of fluid being transferred directly impacts financial agreements.
Multi-Stream,Multi-Station Capability:The S600 can handle complex configurations.It allows for simultaneous metering of both liquids and gases across multiple streams(up to 10 with expansion modules)and multiple stations(up to 2).This makes it incredibly versatile for diverse measurement needs.
High Precision Calculations:All metering calculations are performed using 64-bit(double)precision floating-point numbers for the highest accuracy.Cumulative totals are stored in three separate memory locations(Tri-reg format)to ensure maximum data integrity and prevent data loss.
Wide Measurement Standards Support:The FloBoss S600 is compatible with an extensive list of global measurement standards for both gas and liquid applications,including:
Gas:AGA,ISO,GPA,GERG,GOST
Liquid:API,ASTM,GPA,NORSOK
Distributed Processing:The S600 uses distributed processing to achieve maximum performance.The main CPU incorporates a hardware floating-point processor,and each additional I/O card also has its own local processing capabilities.This architecture offloads tasks from the main CPU,enhancing overall system efficiency and responsiveness.
Multiple Communication Interfaces:It offers robust connectivity options for integration into various control systems:
Ethernet(up to two ports on S600+):Supporting Modbus/TCP and Modbus over Ethernet.The S600+model typically includes two 100Mb/s full-duplex Ethernet ports as standard.
Serial Ports:Multiple configurable EIA-232(RS-232)and EIA-422/EIA-485 serial ports.
HART:With optional P188.R2 modules,it can support HART communication for smart field devices,offering advanced diagnostics and remote configuration.
USB Port:The S600+includes a rear USB port for downloading reports to a flash drive.
Embedded Web Server(S600+):The S600+has an embedded web server that allows for remote access and management,enhancing operational efficiency and ease of maintenance.
Meter Proving Applications:It supports various meter proving methods,including compact,uni-directional,bi-directional,master meter,and dual chronometry,with support for 1,2,or 4 sphere switches.Each S600 can support up to two provers.
LogiCalc™User Language:It features LogiCalc™,a powerful,user-friendly language that allows for custom configurations and double-precision mathematical functions.
Local Display and Keypad:The unit features a display and keypad,enabling operators to review or modify system parameters directly on-site without needing a separate PC.
Robust and Reliable Design:Built for demanding industrial environments,the FloBoss S600 ensures high reliability and a long calibration period,which helps reduce maintenance costs.
FloBoss S600+(Plus)Enhancements
The FloBoss S600+is an evolution of the S600,building on its success with key improvements:
Redesigned CPU:Incorporates recent technological advances for enhanced performance.
Increased Communication:Standard two Ethernet ports(previously one standard,one optional)and more serial ports.
Extended Data Logging:Improved data logging facilities.
Backward Compatible:Fully backward compatible with existing S600 installations.
Faster Configuration Downloads:Significantly faster download times for configurations(approx.10 times faster).
