描述
主要产品详情及功能
智能I/O板：P144.R4不仅仅是一块简单的I/O卡，更是一块“智能”板。这意味着它拥有独立的本地处理能力，可以减轻FloBoss S600/S600+主CPU的负担。它可以处理输入和输出在工程单位和现场值之间的转换，并可以直接运行后台测试和PID（比例-积分-微分）循环。
FloBoss S600/S600+的核心I/O：该板作为FloBoss S600+的标准组件提供，通常是S600和S600+系统中的主要I/O模块。它提供多种输入和输出类型：
模拟输入：接收模拟信号（例如来自压力或温度变送器的4-20 mA信号）来测量物理量。
数字输入：接收来自开关、继电器和其他二进制设备的开/关信号。
数字输出：提供开/关信号以控制执行器、继电器或指示器。
脉冲输入：专门设计用于接收来自各种流量计（例如涡轮流量计、容积式流量计）的脉冲信号。S600+通常配备一个P144模块，该模块包含一个脉冲夹层(P148)模块作为子板，增强了其脉冲输入功能。
测量和控制：它是FloBoss S600功能的关键，使其能够：
通过从流量计和其他传感器收集精确数据来执行财务流量测量。
支持液体和气体的多流路和多站应用。
执行PID控制以实现流量平衡和调度。
“R4”标识：“R4”表示该电路板的修订版或版本。这表明它是一个更新版本，包含先前版本（例如R1、R2、R3）的增强功能或更改。这些修订通常包括稳定性提升、新功能或组件更新。
分布式处理：如上所述，P144.R4的智能特性促成了FloBoss S600的分布式处理架构，该架构通过分配计算负载来最大限度地提高系统整体性能。
坚固的工业设计：作为关键工业流量计算机的组件，P144.R4采用坚固的组件构建，可承受工业环境的恶劣条件，确保高可靠性和长期稳定性。
通用规格（适用于FloBoss S600/S600+中的P144系列）
类型：智能I/O板（数字、模拟、脉冲）
兼容性：艾默生FloBoss S600和S600+流量计算机
I/O容量：提供数字输入、数字输出和模拟输入的组合。与P148脉冲夹层板结合使用时，可提供脉冲输入功能。具体通道数可能因具体配置或相关夹层板而异。
工作电压：通常由FloBoss S600机箱供电（例如24 VDC）。
精度：专为满足财务计量要求而设计的高精度产品（FloBoss S600以64位精度执行计算）。
环境等级：适用于工业级工作温度（例如-10°C至+60°C），并且具有抗湿气和振动的能力。
原产国：通常为美国。
典型应用
艾默生P144.R4是FloBoss S600/S600+流量计算机在以下行业运行的基础：
石油和天然气：用于在管道、终端和加工厂中对原油、精炼产品和天然气进行高精度财务计量和贸易交接。
化工和石化：用于精确测量和控制流体。
水和废水：用于高级流量管理和计费应用。
任何需要高精度流量测量和从各种现场仪表进行可靠数据采集的应用。
Key Product Details and Functions
Intelligent I/O Board:The P144.R4 is more than just a simple I/O card;it’s an”intelligent”board.This means it has its own local processing capabilities,offloading tasks from the main CPU of the FloBoss S600/S600+.It handles the conversion of inputs and outputs between engineering units and field values and can run background tests and PID(Proportional-Integral-Derivative)loops directly.
Core I/O for FloBoss S600/S600+:This board is supplied as a standard component with the FloBoss S600+and is typically the primary I/O module in both S600 and S600+systems.It provides a versatile mix of input and output types:
Analog Inputs:Accepts analog signals(e.g.,4-20 mA from pressure or temperature transmitters)to measure physical quantities.
Digital Inputs:Receives on/off signals from switches,relays,and other binary devices.
Digital Outputs:Provides on/off signals to control actuators,relays,or indicators.
Pulse Inputs:Specifically designed to receive pulse signals from various flow meters(e.g.,turbine meters,positive displacement meters).The S600+is typically supplied with a P144 module that includes a Pulse Mezzanine(P148)module as a daughterboard,which enhances its pulse input capabilities.
Measurement and Control:It’s essential for the FloBoss S600’s functions,enabling it to:
Perform fiscal flow measurement by collecting accurate data from flow meters and other sensors.
Support multi-stream and multi-station applications for both liquid and gas.
Execute PID control for flow balancing and scheduling.
“R4″Designation:The”R4″indicates a revision or version of the board.This suggests that it’s an updated version incorporating enhancements or changes from previous revisions(e.g.,R1,R2,R3).These revisions often include improved stability,new features,or component updates.
Distributed Processing:As mentioned,the intelligent nature of the P144.R4 contributes to the FloBoss S600’s distributed processing architecture,which maximizes overall system performance by distributing computational load.
Robust Industrial Design:As a component of a critical industrial flow computer,the P144.R4 is built with robust components to withstand the harsh conditions of industrial environments,ensuring high reliability and long-term stability.
General Specifications(Common for P144 series within FloBoss S600/S600+)
Type:Intelligent I/O Board(Digital,Analog,Pulse)
Compatibility:Emerson FloBoss S600 and S600+Flow Computers
I/O Capacity:Provides a combination of digital inputs,digital outputs,and analog inputs.When combined with a P148 Pulse Mezzanine,it provides pulse input capabilities.Specific channel counts can vary depending on exact configuration or associated mezzanine boards.
Operating Voltage:Typically powered by the FloBoss S600 chassis(e.g.,24 VDC).
Accuracy:Designed for high accuracy to support fiscal measurement requirements(the FloBoss S600 performs calculations with 64-bit precision).
Environmental Ratings:Suitable for industrial operating temperatures(e.g.,-10°C to+60°C)and robust against humidity and vibration.
Country of Origin:Often the United States.
Typical Applications
The Emerson P144.R4 is foundational for the operation of FloBoss S600/S600+flow computers in industries like:
Oil and Gas:For highly accurate fiscal metering and custody transfer of crude oil,refined products,and natural gas in pipelines,terminals,and processing plants.
Chemical and Petrochemical:For precise measurement and control of fluid streams.
Water and Wastewater:For advanced flow management and billing applications.
Any application requiring high-accuracy flow measurement and robust data acquisition from a variety of field instruments.
