描述
主要产品详情和功能
HART通信协议支持：P188.R2的主要功能是支持HART协议。HART是一种混合通信协议，允许将数字通信（配置、诊断和实时数据）叠加到现有的4-20 mA模拟仪表回路上。这使得“智能”现场设备（如变送器和执行器）能够发送和接收比4-20 mA信号更详细的信息。
适用于FloBoss S600/S600+流量计算机：它是FloBoss S600和S600+流量计算机的可选扩展模块。这些流量计算机是面板安装的财务流量计算机，用于高精度碳氢化合物液体和气体测量。
流量计算机内部功能：
信号调理：转换和处理来自支持HART的现场设备的模拟和数字信号。
通信接口：作为现场HART设备与FloBoss S600/S600+控制系统之间的桥梁，使流量计算机能够访问这些设备的丰富诊断和配置数据。
诊断和维护：提供对现场设备的高级诊断数据（例如，设备健康状况、性能、校准状态）的访问。这对于预测性维护、故障排除和减少停机时间至关重要。
配置：支持远程配置和重新设置HART现场设备的量程，无需在设备本身进行手动干预。
“R2”标识：“R2”表示电路板的修订版或版本，表明其在早期版本的基础上进行了改进或更新。
工业环境设计：作为一款工业级PCB，P188.R2采用坚固耐用的组件，可承受恶劣的工业环境，包括温度变化、湿度和振动，确保可靠运行。
集成：它可无缝集成到FloBoss S600/S600+流量计算机的模块化架构中，通常可滑入可用插槽。
双HART主站功能：S600+流量计算机配备P188.R2时，可支持双HART主站功能，最多可连接12个通道和50个HART变送器。
典型应用
艾默生P188.R2是使用智能仪表并需要详细设备级信息以优化运营和维护的行业中不可或缺的工具：
石油和天然气：在管道、炼油厂和海上平台中，集成流量计和其他使用HART的变送器，用于精确的碳氢化合物计量（贸易交接）。
化工和石化：适用于过程控制系统，其中支持HART的传感器提供温度、压力、流量和液位等关键数据，从而实现高级诊断和远程管理。
制造业：在各种利用智能仪表提高效率和预测性维护的制造过程中。
远程监控：支持对现场设备进行远程配置和监控，减少昂贵且耗时的现场访问。
Key Product Details and Functions
HART Communication Protocol Support:The primary function of the P188.R2 is to provide support for the HART protocol.HART is a hybrid communication protocol that allows for digital communication(configuration,diagnostics,real-time data)to be superimposed on existing 4-20 mA analog instrument loops.This allows”smart”field devices(like transmitters and actuators)to send and receive more detailed information than what’s available from just the 4-20 mA signal.
For FloBoss S600/S600+Flow Computers:It’s designed as an optional expansion module for the FloBoss S600 and S600+Flow Computers.These flow computers are panel-mount fiscal flow computers used for highly accurate hydrocarbon liquid and gas measurement.
Functionality within the Flow Computer:
Signal Conditioning:Converts and processes both analog and digital signals from HART-enabled field devices.
Communication Interface:Acts as a bridge between HART devices in the field and the FloBoss S600/S600+control system,allowing the flow computer to access rich diagnostic and configuration data from these devices.
Diagnostics and Maintenance:Provides access to advanced diagnostic data from field devices(e.g.,device health,performance,calibration status).This is invaluable for predictive maintenance,troubleshooting,and reducing downtime.
Configuration:Enables remote configuration and re-ranging of HART field devices without the need for manual intervention at the device itself.
“R2″Designation:The”R2″indicates a revision or version of the board,suggesting improvements or updates over earlier versions.
Design for Industrial Environments:As an industrial PCB,the P188.R2 is built with robust components to withstand harsh industrial conditions,including temperature variations,humidity,and vibrations,ensuring reliable operation.
Integration:It seamlessly integrates into the modular architecture of the FloBoss S600/S600+flow computers,typically sliding into an available slot.
Dual HART Master Capability:The S600+flow computer,when equipped with the P188.R2,can support Dual HART master capability,allowing for up to 12 channels and connection to up to 50 HART transmitters.
Typical Applications
The Emerson P188.R2 is indispensable in industries that utilize smart instrumentation and require detailed device-level information for optimized operations and maintenance:
Oil and Gas:In pipelines,refineries,and offshore platforms for precise fiscal(custody transfer)measurement of hydrocarbons,integrating flow meters and other transmitters that use HART.
Chemical and Petrochemical:For process control systems where HART-enabled sensors provide critical data on temperature,pressure,flow,and level,allowing for advanced diagnostics and remote management.
Manufacturing:In various manufacturing processes that leverage smart instrumentation for improved efficiency and predictive maintenance.
Remote Monitoring:Enables remote configuration and monitoring of field devices,reducing the need for costly and time-consuming site visits.
