描述
ENTERASYS A2H124-24FX-RH是一款可堆叠式快速以太网交换机，以下是其产品详情：
接口类型
MT-RJ端口：1-24号端口为MT-RJ接口，支持100Base-FX标准。
RJ45端口：25和26号端口为RJ45接口，支持10/100/1000Base-TX标准，具有自动感应和自动协商功能，可用于堆叠，在独立模式下也可用于主机连接和交换机间链路。
SFP端口：27和28号端口为SFP插槽，支持可选的Mini-GBIC模块，可实现1000Base-FX光纤连接和1000Base-T铜缆连接。
电源参数
交流输入：输入电压范围为110-240VAC，输入电流最大为1A，频率为50-60Hz。
直流输入：部分资料显示该型号可能配备双直流输入电源模块，输入电压为DC 48V±15%，具有在线热更换功能，支持AC电源故障无缝切换。
处理器和内存
处理器：采用MPC8241处理器，时钟频率为266MHz，配有33MHz的PCI和133MHz的SDRAM。
内存：动态随机访问内存（DRAM）为128MB，闪存（Flash Memory）为16MB。
物理参数
尺寸：44.1cm（宽）×4.4cm（高）×21.0cm（深）。
重量：净重约2.7kg，毛重约3.5kg。
其他参数
工作温度：0℃-45℃。
相对湿度：5%-95%非凝结。
堆叠能力：可组建最多8台A2系列交换机的堆叠集群。
The ENTERASYS A2H124-24FX-RH is a stackable Fast Ethernet switch.Product details are as follows:
Interface Type
MT-RJ Ports:Ports 1-24 are MT-RJ interfaces supporting the 100Base-FX standard.
RJ45 Ports:Ports 25 and 26 are RJ45 interfaces supporting the 10/100/1000Base-TX standard with auto-sensing and auto-negotiation capabilities.They can be used for stacking or,in standalone mode,for host connections and inter-switch links.
SFP Ports:Ports 27 and 28 are SFP slots supporting optional Mini-GBIC modules for 1000Base-FX fiber connections and 1000Base-T copper connections.
Power Supply Specifications
AC Input:Input voltage range is 110-240VAC,with a maximum input current of 1A and a frequency of 50-60Hz.DC Input:Some information indicates this model may be equipped with dual DC input power modules with an input voltage of 48V DC±15%.These modules feature online hot-swap functionality and support seamless failover in the event of an AC power failure.
Processor and Memory
Processor:MPC8241 processor with a clock frequency of 266MHz,33MHz PCI and 133MHz SDRAM.
Memory:128MB of dynamic random access memory(DRAM)and 16MB of flash memory.
Physical Parameters
Dimensions:44.1cm(width)×4.4cm(height)×21.0cm(depth).
Weight:Net weight approximately 2.7kg,gross weight approximately 3.5kg.
Other Parameters
Operating Temperature:0°C-45°C.
Relative Humidity:5%-95%non-condensing.
Stacking Capability:Up to 8 A2 series switches can be stacked together.
