描述
EPRO MMS6350是一款数字式超速保护系统模块，属于Emerson（艾默生）公司的MMS6000系列，主要用于工业旋转机械的转速监测和超速保护。以下是其产品详情：
基本信息
品牌：EPRO
型号：MMS6350
产品类型：数字式超速保护系统模块
适用范围：适用于蒸汽机、燃汽机、水轮机、压缩机、风扇、离心机等旋转机械。
技术参数
信号输入：电压输入范围为0-27.3V/最大0-30V DC，输入阻抗大于100KΩ，频率范围为0-16kHz（-3dB）±20%。
传感器供电：与系统电压和供电电压之间电隔离，具有开路和短路保护。
供电电压：26.75V DC，供电电流35mA，允许电压范围为18-31.2V DC。
测量范围：输入信号频率0-20kHz，最大转速65535rpm。
输出信号：每个MMS6350模块有两路0/4-20mA电流输出，与转速成正比，精度为0.1%；一路TTL输出，具有开路和短路保护；还有六个可单独设置的二进制输出。
功能特点
三通道设计：采用三取二形式转速测量系统，每个MMS6350模块分别采集一个脉冲传感器的信号，通过微处理器对所有通道的脉冲输入及输出信号进行比较后，采用三取二逻辑报警输出，提高了系统的可靠性和安全性。
多种测量模式：可测量由齿盘触发的脉冲信号，并根据两个信号相间隔的时间来计算转速，有每转n次测量和每转一次测量两种方式。
自检功能：内置传感器及模块通道正常自检功能，可在运行中对系统进行自我检查，确保系统的正常运行。
通讯接口丰富：具备RS232/RS485端口，用于现场组态及通讯，还可选择Profibus-DP接口，方便与其他设备进行数据交换和网络连接。
密码保护：每个监测器都有密码保护，提高了系统的安全性。
峰值记忆：集成峰值记忆功能，可读出机器关闭前出现的最大转速值，为评估超速对机械机器负载的影响提供重要信息。
The EPRO MMS6350 is a digital overspeed protection system module,belonging to Emerson’s MMS6000 series,primarily used for speed monitoring and overspeed protection of industrial rotating machinery.Below are its product details:
Basic Information
Brand:EPRO
Model:MMS6350
Product Type:Digital Overspeed Protection System Module
Applications:Suitable for rotating machinery such as steam engines,gas turbines,water turbines,compressors,fans,and centrifuges.
Technical Parameters
Signal Input:Voltage input range 0-27.3V/maximum 0-30V DC,input impedance greater than 100KΩ,frequency range 0-16kHz(-3dB)±20%.
Sensor Power Supply:Electrically isolated from system voltage and supply voltage,with open-circuit and short-circuit protection.
Supply Voltage:26.75V DC,supply current 35mA,allowable voltage range 18-31.2V DC.
Measurement Range:Input signal frequency 0-20kHz,maximum speed 65535rpm.
Output Signal:Each MMS6350 module has two 0/4-20mA current outputs,proportional to the speed,with an accuracy of 0.1%;one TTL output with open-circuit and short-circuit protection;and six individually configurable binary outputs.
Features:
Three-Channel Design:Employs a 3-out-of-2 speed measurement system.Each MMS6350 module acquires a signal from a pulse sensor.The microprocessor compares the pulse input and output signals from all channels and uses a 3-out-of-2 logic for alarm output,improving system reliability and safety.
Multiple Measurement Modes:Can measure pulse signals triggered by the gear disc and calculate the speed based on the time interval between two signals.Two measurement modes are available:n measurements per revolution and one measurement per revolution.
Self-Test Function:Built-in self-test function for sensors and module channels allows for system self-checking during operation,ensuring normal system operation.
Extensive Communication Interfaces:Equipped with RS232/RS485 ports for field configuration and communication,and an optional Profibus-DP interface for easy data exchange and network connectivity with other devices.
Password Protection:Each monitor is password protected,enhancing system security.
Peak Memory:Integrated peak memory function allows the system to read the maximum RPM value before machine shutdown,providing crucial information for assessing the impact of overspeed on mechanical load.
