描述
EPRO MMS6410是艾默生MMS6000机器监测系统的一部分，是一款双通道测量放大器，主要用于监测旋转机械的振动等参数。以下是其产品详情：
基本信息
品牌：EPRO
型号：MMS6410
产品类型：振动监测板、双通道测量放大器
产地：德国
技术参数
传感器输入：两路独立传感器输入，通道1用于涡流传感器，通道2用于电动式或压电式传感器。信号输入为差值输入，与系统供电电源采用光电隔离，具有开路和短路保护。
输入阻抗：通道1和通道2的输入阻抗均大于100kΩ。
输入电压范围：通道1输入电压范围为0-20V；通道2输入电压范围为-5V至15V。
信号频率范围：通道1信号频率范围为5/10–50–1000/1600Hz（符合VDI2056/DIN45666/ISO3945标准），10-1000Hz带有相应滤波特性；通道2信号频率范围与通道1相同。
输出类型：4-20mA电流输出。
输出负载：500Ω。
供电电压：24VDC。
尺寸：宽30mm（6TE），高128mm（3HE），长160mm。
重量：净重约320g，总重约450g。
功能特点
双通道设计：可同时测量两个独立信号，每个测量通道可单独运行，也可计算两个通道测量结果的和或差值。
多种参数测量：可测量位移、角度、力、扭振等静态和动态物理量，适用于涡轮机械保护系统。
高精确度：精确度为测量范围的0.5%，可调值的0.5%。
抗干扰能力强：传感器电源对地平衡，可抑制工业环境中的干扰。
丰富的通讯接口：具备RS232接口，用于配置和读取测量结果；RS485接口可连接到EPRO的MMS6800分析和诊断系统或主计算机。
自检功能：内部模件连续监测传感器信号、接线、供电电压、组态参数、测量值、运行温度等，模块故障原因可通过通讯接口读出。
The EPRO MMS6410,part of the Emerson MMS6000 machine monitoring system,is a dual-channel measurement amplifier primarily used for monitoring parameters such as vibration in rotating machinery.Below are its product details:
Basic Information
Brand:EPRO
Model:MMS6410
Product Type:Vibration Monitoring Board,Dual-Channel Measurement Amplifier
Origin:Germany
Technical Specifications
Sensor Input:Two independent sensor inputs;Channel 1 for eddy current sensors,Channel 2 for electrodynamic or piezoelectric sensors.The signal input is differential and opto-isolated from the system power supply,with open-circuit and short-circuit protection.
Input Impedance:The input impedance of both Channel 1 and Channel 2 is greater than 100kΩ.
Input Voltage Range:Channel 1 input voltage range is 0-20V;Channel 2 input voltage range is-5V to 15V.
Signal Frequency Range:Channel 1 signal frequency range is 5/10–50–1000/1600Hz(compliant with VDI2056/DIN45666/ISO3945 standards),with corresponding filtering characteristics from 10-1000Hz;Channel 2 signal frequency range is the same as Channel 1.
Output Type:4-20mA current output.
Output Load:500Ω.
Power Supply Voltage:24VDC.
Dimensions:Width 30mm(6TE),Height 128mm(3HE),Length 160mm.
Weight:Net weight approx.320g,Gross weight approx.450g.
Features:
Dual-channel design:Can simultaneously measure two independent signals;each measurement channel can operate independently,or the sum or difference of the measurement results from two channels can be calculated.
Multiple parameter measurement:Can measure static and dynamic physical quantities such as displacement,angle,force,and torsional vibration;suitable for turbomachinery protection systems.
High accuracy:Accuracy is 0.5%of the measurement range,with an adjustable value of 0.5%.
Strong anti-interference capability:The sensor power supply is balanced to ground,suppressing interference in industrial environments.
Rich communication interfaces:Equipped with an RS232 interface for configuring and reading measurement results;an RS485 interface for connection to EPRO’s MMS6800 analysis and diagnostic system or a host computer.
Self-test function:The internal module continuously monitors sensor signals,wiring,power supply voltage,configuration parameters,measured values,operating temperature,etc.Module fault causes can be read through the communication interface.
