描述
EPRO MMS6620是EPRO MMS 6000机器监控系统中的模拟输入(I/O)卡。它旨在将温度、压力或发电机功率等外部过程信号集成到工业机械的综合监控和分析解决方案中。这使得人们能够更全面地了解机器的健康状况，而不仅仅是振动或位置。
主要特性和规格
功能：模拟输入(I/O)卡。
通道：它具有四个模拟输入通道，可灵活处理各种信号类型。
输入信号类型：该模块可接受不同的标准工业模拟信号：
±1 V
±10 V
0/4…20 mA（电流环）
分辨率：高分辨率16位模数转换确保输入信号的精确测量。
信号转换：将模拟输入信号转换为可通过RS485 EPRO协议传输的数字格式，使数据可供MMS 6000系统内的其他模块以及更高级别的可视化/分析工具使用。
限值监控：
支持最多8个限值，可自由分配给输入通道。这允许您设置关键过程参数的阈值。
提供二进制限值输出，通常为继电器触点或24V直流信号，用于在超过这些限值时触发警报或控制操作。
通道空闲监控：包括对输入通道的“通道空闲”监控，指示每个输入路径的运行状况。
通信接口：
RS232前面板接口：用于使用PC进行本地编程和配置。
RS485 EPRO协议：MMS 6000系统内传输处理数据和配置的主要接口。
电源：
支持卡本身的冗余电源，增强可靠性。
还为其二进制输出提供冗余电源。
物理特性：
外形尺寸：通常为欧式插卡（例如6 TE宽度），设计用于安装在19英寸MMS 6000机架系统中。
尺寸：紧凑型，约2.2厘米（宽）x 12.4厘米（高）x 12.6厘米（深）。
重量：轻，约0.1公斤。
应用：
对于将非振动参数（例如温度、压力、流量、液位、发电机负载等）集成到机器监控系统中至关重要。
能够更全面地了解机器健康状况，并将过程状态与机械行为关联起来。
通过提供全面的分析数据，支持高级诊断和预测性维护策略。
The EPRO MMS6620 is an Analog Input(I/O)Card within the EPRO MMS 6000 machine monitoring system.It’s designed to integrate external process signals,such as temperature,pressure,or generator power,into a comprehensive monitoring and analysis solution for industrial machinery.This allows for a more complete understanding of machine health beyond just vibration or position.
Key Features and Specifications
Function:Analog Input(I/O)Card.
Channels:It features four analog input channels,providing flexibility for various signal types.
Input Signal Types:The module can accept different standard industrial analog signals:
±1 V
±10 V
0/4…20 mA(current loop)
Resolution:High-resolution 16-bit analog-to-digital conversion ensures precise measurement of the input signals.
Signal Conversion:Converts the analog input signals into a digital format that can be transmitted over the RS485 EPRO protocol,making the data available to other modules within the MMS 6000 system and higher-level visualization/analysis tools.
Limit Value Monitoring:
Supports up to 8 limit values,which can be freely assigned to the input channels.This allows you to set thresholds for critical process parameters.
Provides binary limit outputs,typically in the form of relay contacts or 24V DC signals,to trigger alarms or control actions when these limits are exceeded.
Channel Clear Supervision:Includes”Channel Clear”supervision for the input channels,indicating the healthy operation of each input path.
Communication Interfaces:
RS232 Front Socket:For local programming and configuration using a PC.
RS485 EPRO Protocol:The primary interface for communicating processed data and configuration within the MMS 6000 system.
Power Supply:
Supports redundant power supply for the card itself,enhancing reliability.
Also offers redundant power supply for its binary outputs.
Physical Characteristics:
Form Factor:Typically a plug-in card in a Euro format(e.g.,6 TE width),designed to be installed in a 19-inch MMS 6000 rack system.
Dimensions:Compact,approximately 2.2 cm(width)x 12.4 cm(height)x 12.6 cm(depth).
Weight:Light,around 0.1 kg.
Application:
Crucial for integrating non-vibration parameters(like temperature,pressure,flow,level,generator load,etc.)into machine monitoring systems.
Allows for a more holistic view of machine health and enables correlation of process conditions with mechanical behavior.
Supports advanced diagnostics and predictive maintenance strategies by providing comprehensive data for analysis.
