EPRO UES815S产品详情解析
EPRO UES815S是PRÜFTECHNIK（普卢福）集团旗下EPRO品牌推出的一款紧凑型一体化振动监测模块，专为中小型旋转机械（如泵、风机、压缩机、电机）的状态监测与预测性维护设计。该模块集成了振动信号采集、温度监测、报警逻辑控制、现场显示等功能，支持Modbus/PROFIBUS通信，可独立运行或集成至EPRO VIBGUARD 3000/5000等监测系统。以下从产品定位、核心功能、技术规格、应用场景及选型建议五方面详细解析：
一、产品定位与核心功能
所属系统
EPRO Condition Monitoring Ecosystem：UES815S作为基础型监测模块，可与EPRO VIBNODE、VIBGUARD系列形成产品矩阵，覆盖从简单到复杂的监测需求。
模块类型：
单通道振动+温度监测模块：支持加速度/速度/位移振动测量与PT100温度监测，适用于单点关键设备监测（如电机轴承、风机叶轮）。
现场显示型：内置3.5英寸彩色液晶屏，可实时显示振动幅值、频谱、温度等参数，支持现场故障诊断。
核心优势
高性价比：相比MMS6620等高端模块，UES815S以更低成本实现基础振动监测，满足预算有限场景的需求。
紧凑设计：尺寸120mm×80mm×40mm，重量<0.5kg，支持DIN导轨安装或面板安装，节省空间。
多参数监测：集成振动（加速度/速度/位移）+温度，支持机械故障与热故障联合分析（如轴承过热导致润滑失效）。
快速部署：支持即插即用，通过EPRO ConfigTool软件快速配置参数，无需复杂编程。
工业级可靠性：防护等级IP65，适应-20℃~+70℃环境，满足CE/UL认证，适用于恶劣工业现场。
二、技术规格与参数
1.振动信号采集
参数规格
通道数1通道（可扩展至2通道，型号如UES815S-2）
传感器类型加速度（IEPE）、速度（磁电式）、位移（电涡流）
输入范围加速度：±10g（默认）；速度：0~100mm/s（峰值）；位移：0~1mm（峰峰值）
采样频率12.8kHz（默认），可配置至25.6kHz（需降频使用）
分辨率16位ADC，动态范围>80dB
抗混叠滤波硬件滤波（截止频率5kHz）+软件数字滤波（如低通滤波器）
EPRO UES815S Product Details
The EPRO UES815S,launched by EPRO,a brand within the PRÜFTECHNIK Group,is a compact,integrated vibration monitoring module designed for condition monitoring and predictive maintenance of small and medium-sized rotating machinery(such as pumps,fans,compressors,and motors).The module integrates vibration signal acquisition,temperature monitoring,alarm logic control,and on-site display.It supports Modbus/PROFIBUS communication and can operate independently or be integrated into monitoring systems such as the EPRO VIBGUARD 3000/5000.The following provides a detailed analysis of the product’s positioning,core functions,technical specifications,application scenarios,and selection recommendations:
1.Product Positioning and Core Functions
EPRO Condition Monitoring Ecosystem:As a basic monitoring module,the UES815S forms a product matrix with the EPRO VIBNODE and VIBGUARD series,covering simple to complex monitoring needs.Module Type:
Single-Channel Vibration+Temperature Monitoring Module:Supports acceleration/velocity/displacement vibration measurement and PT100 temperature monitoring,suitable for single-point monitoring of critical equipment(such as motor bearings and fan impellers).
On-Site Display:A built-in 3.5-inch color LCD displays real-time parameters such as vibration amplitude,spectrum,and temperature,supporting on-site fault diagnosis.
Core Advantages:
High Cost-Effective:Compared to high-end modules like the MMS6620,the UES815S provides basic vibration monitoring at a lower cost,meeting the needs of budget-constrained scenarios.
Compact Design:Measuring 120mm×80mm×40mm and weighing less than 0.5kg,it supports DIN rail or panel mounting for space-saving installation.
Multi-Parameter Monitoring:Integrated vibration(acceleration/velocity/displacement)and temperature monitoring support combined analysis of mechanical and thermal faults(such as bearing overheating leading to lubrication failure).
Quick Deployment:Supports plug-and-play operation and rapid parameter configuration via EPRO ConfigTool software,eliminating the need for complex programming.Industrial-grade reliability:IP65 protection,suitable for-20°C to+70°C environments,CE/UL certified,suitable for harsh industrial environments.
II.Technical Specifications and Parameters
1.Vibration Signal Acquisition
Parameters
Number of Channels:1(expandable to 2 channels,model e.g.,UES815S-2)
Sensor Type:Acceleration(IEPE),Velocity(Magnetoelectric),Displacement(Eddy Current)
Input Range:Acceleration:±10g(default);Velocity:0-100mm/s(peak);Displacement:0-1mm(peak-to-peak)
Sampling Frequency:12.8kHz(default),configurable to 25.6kHz(requires downsampling)
Resolution:16-bit ADC,dynamic range>80dB
Anti-aliasing Filter:Hardware filtering(5kHz cutoff frequency)+software digital filtering(e.g.,low-pass filter)
