描述
Fanuc A16B-1212-0950是一款由发那科(FANUC)生产的电源单元(PSU)。它通常以印刷电路板(PCB)的形式存在，专门用于CNC(计算机数控)系统。
以下是关于该产品的一些详细信息：
主要功能和特点
电源供应：它的主要作用是为FANUC CNC系统提供稳定的直流电源输出，确保控制系统能够持续运行。它能够提供+5V,+15V,-15V,+24V,和+24E等电压，并输出EN信号给主电路板。
内置输入单元功能：这款电源单元集成了输入单元功能，因此不需要额外准备继电器或独立的输入单元来控制交流输入的开关。交流电源可以直接连接到该电源单元。
兼容性：A16B-1212-0950通常用于FANUC Series 0型号C、D和F控制系统，包括0MC、0MD、0MF、0TC、0TD、0TF等多种变体。
安装和连接：它设计用于轻松安装和拆卸，可以直接连接到主印刷电路板。所有的交流输入和直流输出都通过连接器连接，简化了安装过程。
安全标准：该电源单元带有CE标志，表明其符合欧盟的安全标准。
保护机制：它集成了多种保护机制，可以保护控制系统免受电源波动、电压尖峰和其他电气异常的影响，从而防止敏感组件损坏并延长系统寿命。
紧凑设计：A16B-1212-0950采用紧凑且节省空间的设计，适合安装空间有限的环境，便于集成到控制柜或外壳中。
服务插座：该单元带有一个交流服务插座，与电源单元同步开关，可用于为风扇电机等单元供电。
警报显示：当发生报警情况（例如输出错误）导致电源单元关闭时，报警显示LED（红色）会亮起并保持亮起状态，直到通过按下OFF开关或关闭交流电源来清除报警情况。
规格概览
型号:A16B-1212-0950
制造商:FANUC
类型:电源单元/PCB电源
输入电压:200/220/230/240 VAC
输出电压:200/220/230/240 VAC(通过CP2或CP3)；以及+5V,+15V,–15V,+24V,+24E(到主电路板)
重量:大约3.00公斤
Fanuc A16B-1212-0950 is a power supply unit(PSU)manufactured by FANUC.It is usually in the form of a printed circuit board(PCB)and is specifically used in CNC(computer numerical control)systems.
Here are some details about this product:
Main functions and features
Power supply:Its main function is to provide stable DC power output for FANUC CNC systems to ensure that the control system can continue to operate.It can provide voltages such as+5V,+15V,-15V,+24V,and+24E,and output EN signals to the main circuit board.
Built-in input unit function:This power supply unit integrates the input unit function,so there is no need to prepare additional relays or independent input units to control the switching of AC input.AC power can be directly connected to this power supply unit.
Compatibility:The A16B-1212-0950 is commonly used in FANUC Series 0 Model C,D,and F control systems,including multiple variants such as 0MC,0MD,0MF,0TC,0TD,0TF,etc.
Mounting and Connections:It is designed for easy installation and removal and can be directly connected to the main printed circuit board.All AC inputs and DC outputs are connected through connectors,simplifying the installation process.
Safety Standards:The power supply unit carries the CE mark,indicating that it complies with EU safety standards.
Protection Mechanisms:It integrates multiple protection mechanisms to protect the control system from power fluctuations,voltage spikes,and other electrical anomalies,thereby preventing damage to sensitive components and extending system life.
Compact Design:The A16B-1212-0950 adopts a compact and space-saving design,suitable for environments with limited installation space,and is easy to integrate into control cabinets or enclosures.
Service Socket:The unit comes with an AC service socket that switches synchronously with the power supply unit and can be used to power units such as fan motors.
Alarm Display:When an alarm condition(e.g.,output error)occurs causing the power supply unit to shut down,the alarm display LED(red)illuminates and remains illuminated until the alarm condition is cleared by pressing the OFF switch or turning off the AC power.
Specifications Overview
Model:A16B-1212-0950
Manufacturer:FANUC
Type:Power Supply Unit/PCB Power Supply
Input Voltage:200/220/230/240 VAC
Output Voltage:200/220/230/240 VAC(via CP2 or CP3);and+5V,+15V,–15V,+24V,+24E(to the main circuit board)
Weight:Approx.3.00 kg
