描述
FIREYE 45UV5是一系列自检式紫外线火焰探测器,采用紫外光谱技术检测火焰中的紫外线辐射,主要用于工业燃烧设备的火焰监测与保护。以下是其产品详情:
型号规格:常见型号为45UV5-1101,此外还有45UV5-1000、45UV5-1010等型号。
检测类型:紫外线(UV)。
探测范围:0至15英尺(约4.6米)。
视野:90度。
响应时间:0.2秒。
工作温度:-40°C至85°C。
防护等级:IP65。
尺寸:直径2.75英寸(70毫米)×长度3.75英寸(95毫米)。
重量:1.25磅(0.57公斤)。
安装方式:1英寸BSP螺纹。
电气连接:2线电缆。
外壳材质:压铸铝。
该系列探测器灵敏度高、可靠性强,具有自检功能,能在各种恶劣环境下稳定工作,可与Flame-Monitor™、BurnerLogix™等Fireye控制型号配合,为工业燃烧器、锅炉、焚化炉等设备提供火焰安全保护和监测系统。
The FIREYE 45UV5 is a series of self-testing ultraviolet flame detectors that use ultraviolet spectroscopy to detect ultraviolet radiation in flames.They are primarily used for flame monitoring and protection in industrial combustion equipment.Below are the product details:
Model Specifications:The most common model is the 45UV5-1101,with other models including the 45UV5-1000 and 45UV5-1010.
Detection Type:Ultraviolet(UV).
Detection Range:0 to 15 feet(approximately 4.6 meters).
Field of View:90 degrees.
Response Time:0.2 seconds.
Operating Temperature:-40°C to 85°C.
Ingress Protection:IP65.
Dimensions:2.75 inches(70 mm)diameter x 3.75 inches(95 mm)length.
Weight:1.25 lb(0.57 kg).
Mounting:1-inch BSP thread.Electrical Connection:2-wire cable.
Casing Material:Die-cast aluminum.
This series of detectors offers high sensitivity,strong reliability,and a self-test function,ensuring stable operation in a variety of harsh environments.They can be used with Fireye control models such as Flame-Monitor™and BurnerLogix™to provide flame safety protection and monitoring systems for industrial burners,boilers,incinerators,and other equipment.
