一、产品概述
FISHER-ROSEMOUNT KJ1501X1-BC1是艾默生（Emerson）旗下的一款双路直流电源模块，专为工业自动化系统设计，尤其适用于艾默生DeltaV分布式控制系统（DCS）及类似工业环境。其核心功能包括高可靠性供电、宽输入范围适应性及紧凑化设计，广泛应用于电力、化工、石油、制药等领域。
二、核心功能与特点
双路直流电源输出
支持同时输出两路直流电源，满足工业设备对冗余供电的需求，提升系统稳定性。
典型输出电压为12VDC/24VDC，最大输出电流分别为13A（12VDC）和8A（24VDC），总功率达10.2W。
宽输入范围与高效性
输入电压范围支持12VDC至24VDC，适应不同工业电源环境。
采用高效设计，热耗低，降低能源消耗和设备维护成本。
工业级环境适应性
工作温度范围-40℃至+85℃，适用于极端温度环境。
防护等级IP65，具备防尘、防水能力，外壳为耐腐蚀铝合金材质，支持螺纹连接与壁挂式安装。
冗余与高可靠性
支持冗余配置，确保系统高可用性。
采用高品质元器件和制造工艺，可在恶劣工业环境中长期稳定运行。
兼容性与扩展性
与艾默生DeltaV系统无缝集成，适用于模拟量输入（AI）、数字量输入（DI）等信号处理场景。
支持模块化设计，便于维护和升级。
三、技术参数
参数类别规格
输入电压12VDC至24VDC
输出电压12VDC（13A）、24VDC（8A）、5.1VDC/3.4VDC（各2A）
总功率10.2W（最大）
工作温度-40℃至+85℃
防护等级IP65
外壳材质铝合金（耐腐蚀）
安装方式壁挂式
1.Product Overview
FISHER-ROSEMOUNT KJ1501X1-BC1 is a dual-channel DC power module under Emerson.It is specially designed for industrial automation systems and is especially suitable for Emerson DeltaV distributed control system(DCS)and similar industrial environments.Its core functions include high reliability power supply,wide input range adaptability and compact design,and are widely used in power,chemical,petroleum,pharmaceutical and other fields.
2.Core functions and features
Dual DC power supply output
It supports the output of two DC power sources simultaneously,meets the demand for redundant power supply of industrial equipment and improves system stability.
The typical output voltage is 12VDC/24VDC,the maximum output current is 13A(12VDC)and 8A(24VDC),respectively,and the total power is 10.2W.
Wide input range and high efficiency
The input voltage range supports 12VDC to 24VDC,adapting to different industrial power supply environments.
Adopt efficient design,low heat consumption,and reduce energy consumption and equipment maintenance costs.
Industrial-grade environmental adaptability
The operating temperature range is-40℃to+85℃,suitable for extreme temperature environments.
Protection level IP65,with dust-proof and waterproof capabilities,the shell is made of corrosion-resistant aluminum alloy,and supports threaded connection and wall-mounted installation.
Redundancy and high reliability
Supports redundant configuration to ensure high system availability.
It adopts high-quality components and manufacturing processes to operate stably for a long time in harsh industrial environments.
Compatibility and Extensibility
Seamlessly integrated with Emerson DeltaV system,suitable for signal processing scenarios such as analog input(AI),digital input(DI).
Supports modular design for easy maintenance and upgrade.
3.Technical parameters
Parameter Category Specifications
Input voltage 12VDC to 24VDC
Output voltage:12VDC(13A),24VDC(8A),5.1VDC/3.4VDC(2A each)
Total power:10.2W(maximum)
Operating temperature-40℃to+85℃
Protection level IP65
Housing material Aluminum alloy(corrosion-resistant)
Installation method Wall-mounted
