FORCE CPU-2CE16 其他

内存:16MB RAM,集成在主VME板上。

接口:具备以太网、SCSI、键盘(KBD)和串行接口。

特性:属于单槽VME单板计算机,支持DRM内存扩展模块。它结合了Sun Microsystems SPARC经典工作站的性能和功能,以及工业标准单槽6U VMEbus板的坚固性和可扩展性,适用于军事、航空航天和工业等环境。

基于ARM架构版本:

架构与核心:采用ARM Cortex-A72架构,拥有16个核心。

主频:主频最高可达2.5GHz。

缓存:具备32MB L3缓存。

工艺:采用16nm FinFET工艺技术。

支持内存与存储:支持DDR4、DDR3内存类型,存储接口支持SATA 3.0。

GPU:配备Mali-T880 MP4图形处理器。

分类: 品牌:

描述

FORCE CPU-2CE16有不同类型,常见的是基于VME总线的单板计算机,有基于SPARC架构和ARM架构等不同版本,主要用于工业控制等领域。相关产品详情如下:

基于SPARC架构版本:

处理器:配备40MHz SPARC处理器。

内存:16MB RAM,集成在主VME板上。

接口:具备以太网、SCSI、键盘(KBD)和串行接口。

特性:属于单槽VME单板计算机,支持DRM内存扩展模块。它结合了Sun Microsystems SPARC经典工作站的性能和功能,以及工业标准单槽6U VMEbus板的坚固性和可扩展性,适用于军事、航空航天和工业等环境。

基于ARM架构版本:

架构与核心:采用ARM Cortex-A72架构,拥有16个核心。

主频:主频最高可达2.5GHz。

缓存:具备32MB L3缓存。

工艺:采用16nm FinFET工艺技术。

支持内存与存储:支持DDR4、DDR3内存类型,存储接口支持SATA 3.0。

GPU:配备Mali-T880 MP4图形处理器。

视频编解码:支持H.265、H.264、VC-1、MPEG-2、MPEG-4、AVS、AVS+等视频编码和解码格式。

通用参数:

工作电压:24V DC。

功耗:5W。

工作温度:工作温度范围为-20℃至+70℃,存储温度范围为-40℃至+85℃。

湿度范围:5%至95%(非冷凝)。

尺寸重量:尺寸约为100mm×70mm×30mm,重量约0.5kg。

通信接口:具备以太网、RS485接口,支持CAN总线协议。

防护等级:IP65。

认证:通过CE、UL、RoHS认证。

The FORCE CPU-2CE16 comes in various types.A common VMEbus-based single-board computer(SBC)is available in SPARC and ARM architecture versions,primarily for industrial control and other applications.Product details are as follows:

SPARC Architecture Version:

Processor:Equipped with a 40MHz SPARC processor.

Memory:16MB of RAM,integrated on the main VME board.

Interfaces:Ethernet,SCSI,keyboard(KBD),and serial interfaces.

Features:A single-slot VME single-board computer with support for a DRM memory expansion module.It combines the performance and functionality of Sun Microsystems’classic SPARC workstations with the ruggedness and scalability of an industry-standard single-slot 6U VMEbus board,making it suitable for military,aerospace,and industrial environments.

ARM Architecture Version:

Architecture and Cores:Utilizes the ARM Cortex-A72 architecture with 16 cores.

Frequency:Up to 2.5GHz.

Cache:32MB of L3 cache.Process:Utilizes 16nm FinFET process technology.

Memory and Storage Support:Supports DDR4 and DDR3 memory types,and the storage interface supports SATA 3.0.

GPU:Equipped with a Mali-T880 MP4 graphics processor.

Video Codec:Supports H.265,H.264,VC-1,MPEG-2,MPEG-4,AVS,AVS+,and other video encoding and decoding formats.

General Parameters:

Operating Voltage:24V DC.

Power Consumption:5W.

Operating Temperature:Operating temperature range:-20°C to+70°C,storage temperature range:-40°C to+85°C.

Humidity Range:5%to 95%(non-condensing).

Dimensions and Weight:Approximately 100mm×70mm×30mm,weighing approximately 0.5kg.

Communication Interfaces:Ethernet and RS485 interfaces,supporting the CAN bus protocol.Protection rating:IP65.

Certification:CE,UL,and RoHS certified.
