FOXBORO 130M-N4产品详情解析
FOXBORO 130M-N4是美国福克斯波罗（Foxboro，现属施耐德电气旗下工业自动化品牌）推出的一款高性能气动薄膜调节阀，专为中小流量、高精度流体控制设计，广泛应用于石油化工、电力、制药、食品饮料等行业的自动化系统。该产品结合气动执行机构、智能阀门定位器与模块化阀体结构，具备快速响应、高可靠性、防爆设计、远程通信等特性，适用于常温至中高温（≤220℃）的工艺场景。以下从产品定位、技术规格、核心功能、应用场景及选型建议五方面详细解析：
一、产品定位与核心优势
所属系列
130M系列：130M-N4属于FOXBORO 130M系列，该系列以气动驱动、高精度控制、紧凑设计为特点，适用于中小流量调节、楼宇自动化、实验室设备等场景。
模块化结构：支持阀体、执行机构、定位器分离安装，便于现场维护与升级，降低停机成本。
核心优势
高精度控制：气动执行机构分辨率≤0.05%，配合智能定位器，可实现±0.3%流量精度，满足精细化工、制药等行业的严格需求。
快速响应：执行机构响应时间<0.2秒（从0%到100%开度），支持紧急切断（ESD）功能，确保工艺安全。
智能通信：集成HART 7/Modbus RTU通信协议，可与PLC、DCS系统双向传输阀位、压力、温度、故障代码等数据，实现远程监控与自诊断。
防爆与耐腐蚀：通过ATEX Zone 2、IECEx、CSA防爆认证，阀体材质可选不锈钢（304/316L）、哈氏合金（C-276），适应腐蚀性介质。
二、技术规格与参数
1.阀体参数
参数规格
型号130M-N4
公称通径DN15-DN80（1/2英寸-3英寸），支持法兰连接（ANSI B16.5/DIN PN16-PN40）
压力等级PN16-PN40（Class 150-300），最高耐压4.0MPa
流量特性等百分比（默认）、线性、快开（可根据工艺需求定制）
泄漏等级ANSI/FCI 70-2 Class IV（软密封），泄漏量≤0.01%额定流量
介质温度-20℃至+220℃（普通型），-40℃至+350℃（高温型，需选配特殊材料）
阀体材质碳钢（WCB）、不锈钢（304/316L）、哈氏合金（C-276）
FOXBORO 130M-N4 Product Details
The FOXBORO 130M-N4 is a high-performance pneumatic diaphragm control valve from Foxboro(now an industrial automation brand under Schneider Electric).Designed for high-precision fluid control of small and medium flows,it is widely used in automation systems in industries such as petrochemicals,power generation,pharmaceuticals,and food and beverages.Combining a pneumatic actuator,an intelligent valve positioner,and a modular valve body,it offers fast response,high reliability,explosion-proof design,and remote communication.It is suitable for process applications ranging from ambient to medium-high temperatures(≤220°C).The following is a detailed analysis of the product from five aspects:product positioning,technical specifications,core functions,application scenarios,and selection recommendations:
1.Product Positioning and Core Advantages
Series
130M Series:The 130M-N4 belongs to the FOXBORO 130M series.This series features pneumatic actuation,high-precision control,and a compact design.It is suitable for small and medium-sized flow control,building automation,laboratory equipment,and other applications.
Modular Structure:The valve body,actuator,and positioner can be installed separately,facilitating on-site maintenance and upgrades and reducing downtime costs.
Core Advantages
High-Precision Control:The pneumatic actuator has a resolution of≤0.05%.When combined with the intelligent positioner,it can achieve a flow accuracy of±0.3%,meeting the stringent requirements of industries such as fine chemicals and pharmaceuticals.
Fast Response:The actuator has a response time of<0.2 seconds(from 0%to 100%opening)and supports Emergency Shutdown(ESD)functionality to ensure process safety.Intelligent Communication:Integrated HART 7/Modbus RTU communication protocols enable bidirectional transmission of valve position,pressure,temperature,fault codes,and other data with PLC and DCS systems,enabling remote monitoring and self-diagnosis.
Explosion-proof and Corrosion-resistant:ATEX Zone 2,IECEx,and CSA explosion-proof certifications are available.The valve body is available in stainless steel(304/316L)and Hastelloy(C-276),making it suitable for corrosive media.II.Technical Specifications and Parameters
1.Valve Body Parameters
Parameters Specifications
Model 130M-N4
Nominal Size DN15-DN80(1/2-3 inches),Flange Connections Acceptable(ANSI B16.5/DIN PN16-PN40)
Pressure Rating PN16-PN40(Class 150-300),Maximum Proof Pressure 4.0 MPa
Flow Characteristics:Equal Percentage(Default),Linear,Quick Opening(Customizable Based on Process Requirements)
Leakage Rating:ANSI/FCI 70-2 Class IV(Soft Seal),Leakage≤0.01%of Rated Flow
Media Temperature:-20°C to+220°C(Standard Model),-40°C to+350°C(High-Temperature Model,Special Materials Required)
Valve Body Material:Carbon Steel(WCB),Stainless Steel(304/316L),Hastelloy(C-276)
