描述
基本信息
通道数：8个独立通道
输出类型：0-20mA电流输出
电源：24VDC
尺寸：高度102mm，宽度45mm，深度104mm
重量：约284克
产品认证：CE认证
技术参数
精度：±0.1%
负载能力：500Ω
隔离电压：2500Vrms
工作温度范围：-40°C至+70°C
存储温度范围：-40°C至+85°C
功能特点
高精度：提供高精度的模拟输出信号，确保控制的准确性。
模块化设计：方便安装和维护，每个通道独立隔离，并支持冗余配置。
冗余设计：可作为单个单元使用，也可作为冗余对使用，提高系统的可用性。当主模块出现故障时，备用模块能够立即接管控制任务。
高可靠性：采用工业级元器件，其物理外壳采用压制铝材质，适用于恶劣的工业环境，符合多项电磁兼容性标准。
兼容性强：兼容FOXBORO的多种DCS系统，可与其他功能控制块组合使用，实现更复杂的控制方案。
应用领域：广泛应用于石油和天然气、化工、电力、冶金、造纸、食品、环保等行业，主要用于执行控制逻辑，驱动外部设备或执行器按照预设程序进行动作，如控制阀门、电机等执行机构，控制加料、配料等过程。
Basic Information
Number of Channels:8 independent channels
Output Type:0-20mA current output
Power Supply:24VDC
Dimensions:Height 102mm,Width 45mm,Depth 104mm
Weight:Approximately 284g
Certification:CE
Technical Parameters
Accuracy:±0.1%
Load Capacity:500Ω
Isolation Voltage:2500Vrms
Operating Temperature Range:-40°C to+70°C
Storage Temperature Range:-40°C to+85°C
Features
High Accuracy:Provides highly accurate analog output signals,ensuring control accuracy.
Modular Design:Easy installation and maintenance,with independent isolation for each channel and support for redundant configuration.
Redundant Design:Can be used as a single unit or as a redundant pair,increasing system availability.If the primary module fails,the backup module can immediately take over control tasks.
High Reliability:Utilizing industrial-grade components and an extruded aluminum housing,it is suitable for harsh industrial environments and complies with multiple electromagnetic compatibility standards.Strong Compatibility:Compatible with various FOXBORO DCS systems,it can be combined with other functional control blocks to implement more complex control solutions.
Applications:Widely used in industries such as oil and gas,chemicals,power generation,metallurgy,papermaking,food,and environmental protection.It primarily executes control logic,driving external devices or actuators to perform actions according to preset programs.These include controlling actuators such as valves and motors,and controlling processes such as feeding and batching.
