描述
概述
此底板可作为特定Foxboro控制模块（主要为FCP270现场控制处理器以及可能的Time Strobe模块）的安装平台。它有助于在控制柜内为这些模块提供物理连接和通信路径。
关键细节和功能
制造商：Foxboro（现为施耐德电气/英维思旗下公司）
零件编号：P0926HC
产品类型：模块化底板/PLC模块/机架/底盘
插槽：具有两个用于安装兼容模块的插槽。
方向：设计用于水平安装。
兼容性：
主要用于FCP270现场控制处理器。
也可用于Time Strobe模块，该模块可在工业应用中提供精确的时序控制。
它是Foxboro Evo™和I/A系列系统的标准200系列底板的一部分。
功能：
物理安装：为控制模块提供安全的物理安装点。
电气连接：为安装的模块提供必要的电源和通信电气连接。
现场总线/时间选通脉冲集成：将模块集成到系统的现场总线上，并提供时间选通脉冲输入连接，这对于分布式控制环境中的同步至关重要。
结构：通常由铝制成，表面采用黑色粉末涂层，确保在工业操作环境中的耐用性和长寿命。
设计：紧凑的设计有助于节省控制面板的空间。
安装：易于安装，可使用多种方法安装，通常安装在DIN导轨上（但FCP270的底板本身必须保持水平）。
认证：通常符合CE和RoHS标准，表明其符合欧洲安全和环境标准。
重量：约0.99磅（约0.2公斤）。
应用
FOXBORO P0926HC底板是Foxboro I/A系列DCS安装的基础组件，可用于部署关键的控制和定时模块。Foxboro控制系统广泛应用于各行各业，包括：
石油和天然气
发电
化工和石化加工
纸浆和造纸
制造业
Overview
This baseplate serves as a mounting platform for specific Foxboro control modules,primarily the FCP270 Field Control Processor and potentially Time Strobe modules.It facilitates the physical connection and communication pathways for these modules within a control cabinet.
Key Details and Functions
Manufacturer:Foxboro(now part of Schneider Electric/Invensys)
Part Number:P0926HC
Product Type:Modular Baseplate/PLC Module/Rack/Chassis
Slots:Features two slots for mounting compatible modules.
Orientation:Designed for horizontal mounting.
Compatibility:
Primarily designed for the FCP270 Field Control Processor.
Also used for Time Strobe modules,which provide precise timing control within industrial applications.
It is part of the Standard 200 Series Baseplates for Foxboro Evo™and I/A Series systems.
Function:
Physical Mounting:Provides a secure physical mounting point for the control modules.
Electrical Connection:Offers the necessary electrical connections for power and communication to the mounted modules.
Fieldbus/Time Strobe Integration:Integrates the modules onto the system’s Fieldbus and provides connections for Time Strobe inputs,which are critical for synchronization in distributed control environments.
Construction:Typically constructed from aluminum with a black powder coat finish,ensuring durability and longevity in industrial operating environments.
Design:Compact design that helps save space in control panels.
Installation:Easy to install and can be mounted using various methods,often on a DIN rail(though the baseplate itself must remain horizontal for the FCP270).
Certifications:Often CE and RoHS compliant,indicating adherence to European safety and environmental standards.
Weight:Approximately 0.99 lbs(around 0.2 kg).
Application
The FOXBORO P0926HC baseplate is a foundational component in Foxboro I/A Series DCS installations,enabling the deployment of critical control and timing modules.It is found in various industries that utilize Foxboro’s control systems,including:
Oil&Gas
Power Generation
Chemical and Petrochemical Processing
Pulp and Paper
Manufacturing
