描述
概述
该模块是ABB工业自动化系统的核心组件，通常用作各种应用（包括电机控制和其他工业过程）的控制板。它提供必要的控制逻辑和通信功能。
关键细节和功能
制造商：ABB
零件编号：GDD471A001和2UBA002322R0001（这些编号通常互换使用或一起使用以识别产品）。
产品类型：工业控制板卡/控制板/PLC模块。
主要应用（部分来源标识）：电机控制应用中AF接触器的控制板。这表明它旨在管理接触器的操作，接触器是用于切换电源电路的电气开关，通常用于控制电机。
接触器兼容性：适用于各种ABB AF接触器，功率范围从55 kW–400 V/75 hp到560 kW–400 V/900 hp 480 V，电流最高可达2850 A AC-1/通用。这表明它适用于重要的电力控制应用。
控制功能：
PLC输出：可采用24 V DC PLC输出信号(≥10 mA)。
控制信号：“1”通常表示控制信号和COM之间为24 V DC，而“0”表示无电压。
开/关控制：“ON”和“OFF_N”信号可以并联，形成一个公共的开/关信号。
电压供应限制：包括精确的电压供应限制功能，例如在77%时关闭，在55%时打开。
隔离：确保电路安全隔离，防止单点故障时电压转移，符合IEC/EN 60947-1附录N等标准。这涉及双重绝缘或加强绝缘、防护屏蔽或两者兼有。
通信：一些产品信息提到支持ModbusTCP/IP协议和RJ45接口，表明其具备网络通信功能。它可能支持主从关系（例如，1个主设备，4个从设备）。
电源：通常采用12-24VDC供电。
传输距离：可支持100米的传输距离，特定配置下可达1公里。
耐用性：专为工业环境设计，确保可靠的性能。
状态：通常可从工业自动化零件供应商处购买全新、二手或翻新产品。
应用
ABB GDD471A001 2UBA002322R0001广泛应用于需要可靠、精确控制电气系统和电机的各个工业领域。包括：
电机控制中心(MCC)：用于控制大型工业电机。
配电系统：用于开关设备和控制面板。
通用工业自动化：作为适用于各种过程控制应用的多功能控制板。
制造和生产设施：用于管理机械设备和自动化流程。
Overview
This module is a core component within ABB’s industrial automation systems,often functioning as a control board for various applications,including motor control and other industrial processes.It provides essential control logic and communication capabilities.
Key Details and Functions
Manufacturer:ABB
Part Numbers:GDD471A001 and 2UBA002322R0001(these are often used interchangeably or together to identify the product).
Product Type:Industrial Control Board Card/Control Board/PLC Module.
Primary Application(identified by some sources):Control board for AF contactors in motor control applications.This suggests it’s designed to manage the operation of contactors,which are electrical switches used for switching electrical power circuits,typically for controlling electric motors.
Contactor Compatibility:Suitable for a wide range of ABB AF contactors,from 55 kW–400 V/75 hp up to 560 kW–400 V/900 hp 480 V,and up to 2850 A AC-1/General use.This indicates its use in significant power control applications.
Control Functions:
PLC Output:Can operate with a 24 V DC PLC output signal(≥10 mA).
Control Signal:”1″typically represents 24 V DC between the control signal and COM,while”0″represents no voltage.
ON/OFF Control:”ON”and”OFF_N”signals can be connected in parallel for a common ON/OFF signal.
Voltage Supply Limits:Includes functions for precise voltage supply limits,such as closing at 77%and opening at 55%.
Isolation:Ensures safe isolation of circuits to prevent voltage transfer in case of single failures,complying with standards like IEC/EN 60947-1,Annex N.This involves double or reinforced insulation,protective shields,or a combination.
Communication:Some listings mention ModbusTCP/IP protocol support and an RJ45 interface,indicating network communication capabilities.It might support a master-slave relationship(e.g.,1 master,4 slaves).
Power Supply:Operates typically on 12-24VDC.
Transmission Distance:Can support transmission distances of 100 meters,or up to 1 KM with specific configurations.
Durability:Designed for industrial environments,ensuring reliable performance.
Status:Commonly available as new,used,or refurbished from industrial automation parts suppliers.
Application
The ABB GDD471A001 2UBA002322R0001 is extensively used in various industrial sectors where reliable and precise control of electrical systems and motors is required.This includes:
Motor Control Centers(MCCs):For controlling large industrial motors.
Power Distribution Systems:Within switchgear and control panels.
General Industrial Automation:As a versatile control board for various process control applications.
Manufacturing and Production Facilities:To manage machinery and automated processes.
