描述
GE DS3800HAFA是GE Mark IV系列中的一款辅助功能卡，以下是其产品详情：
基本信息
品牌：GE通用电气。
型号：DS3800HAFA。
系列：Mark IV。
类型：辅助功能卡。
重量：约1.5磅，即约680克。
技术参数
电源：12V DC。
跳线：设有11个跳线，用于对电路板进行配置。
连接器：有1个20针连接器和1个34针连接器。
功能特点
连接方式：模块底部的模块化连接器可与驱动器的连接器自动对齐，形成牢固连接，顶部设有固定杆，用于将卡固定在驱动器的板架中，便于安装和拆卸。
信号处理：配备4个微调电阻器，可由专业技术人员进行调整，以满足特定的电路需求。
状态监测：具有超过35个LED指示灯，可实现实时监测和诊断，便于及时了解系统运行状态，提高系统正常运行时间并减少维护需求。
环境适应性：采用坚固的材料制造，能够承受极端的环境条件，确保在各种工业环境中持续运行。
The GE DS3800HAFA is an auxiliary function card in the GE Mark IV series.Below are its product details:
Basic Information
Brand:GE(General Electric Company)
Model:DS3800HAFA
Series:Mark IV
Type:Auxiliary Function Card
Weight:Approximately 1.5 lbs(680 grams).
Technical Specifications
Power Supply:12V DC.
Jumpers:11 jumpers for board configuration.
Connectors:One 20-pin connector and one 34-pin connector.
Features
Connection:The modular connector on the bottom of the module automatically aligns with the driver’s connector for a secure connection.A top retaining rod secures the card to the driver’s board frame for easy installation and removal.
Signal Processing:Equipped with four adjustable resistors that can be adjusted by a technician to meet specific circuit requirements.
Status Monitoring:Featuring over 35 LED indicators,it enables real-time monitoring and diagnostics,facilitating timely understanding of system operating status,improving system uptime,and reducing maintenance requirements.
Environmental Adaptability:Constructed with robust materials,it can withstand extreme environmental conditions,ensuring continuous operation in a variety of industrial environments.
