描述
GE IC200ALG331是GE Fanuc VersaMax系列中的一款模拟量输出模块，以下是其详细介绍：
基本信息：
产品类型：模拟量输出模块。
品牌：GE Fanuc（现属于Emerson Automation）。
产地：美国。
外观尺寸：尺寸约为122mm×82mm×60mm，重量约0.64磅。
技术参数：
输出通道：4个独立隔离的模拟量输出通道。
信号类型：电压模式为±10VDC，电流模式为4-20mA。
分辨率：16位。
精度：在25°C时，为满量程的±0.1%。
更新速率：最大7ms。
隔离性能：通道间隔离为250V AC连续，输入到逻辑隔离为1500V AC持续1分钟。
电源要求：电流模式需外部24VDC电源，电压模式由内部电源供电，背板电流为5V输出时最大10mA，3.3V输出时最大115mA。
功能特点：
软件配置：可通过软件配置输出类型、默认值、报警阈值和诊断功能，无需跳线或开关。
诊断功能：具备高低限、超/欠量程、断线检测、现场电源丢失、非易失性内存故障等诊断功能。
默认行为：可设置为保持最后状态或在PLC停止或模块错误时缩至零。
现场重新校准：支持通过系统命令进行现场重新校准。
指示灯：具有OK和现场电源（FLD PWR）指示灯，用于显示模块运行状态和现场电源状态。
The GE IC200ALG331 is an analog output module in the GE Fanuc VersaMax series.Here is a detailed description:
Basic Information:
Product Type:Analog Output Module
Brand:GE Fanuc(now part of Emerson Automation)
Country of Origin:USA
Dimensions:Approximately 122mm×82mm×60mm,weight approximately 0.64 lbs.
Technical Specifications:
Output Channels:4 independently isolated analog output channels.
Signal Type:Voltage mode±10VDC,current mode 4-20mA.
Resolution:16-bit.
Accuracy:±0.1%of full scale at 25°C.
Update Rate:Maximum 7ms.
Isolation Performance:Channel-to-channel isolation is 250V AC continuous;input-to-logic isolation is 1500V AC continuous for 1 minute.
Power Requirements:Current mode requires an external 24VDC power supply;voltage mode is powered by an internal power supply.The maximum backplane current is 10mA for 5V output and 115mA for 3.3V output.
Features:
Software Configuration:Output type,default values,alarm thresholds,and diagnostic functions can be configured via software without jumpers or switches.
Diagnostic Functions:Includes high/low limit,over/under range,disconnection detection,field power loss,and non-volatile memory fault diagnostics.
Default Behavior:Can be set to retain the last state or shrink to zero when the PLC stops or a module malfunctions.
Field Recalibration:Supports field recalibration via system commands.
Indicator Lights:Features OK and Field Power(FLD PWR)indicators to display module operating status and field power status.
