描述
GE IC670MDL640是GE Fanuc生产的一款离散输入模块，属于Field Control系列，主要用于工业自动化控制系统。以下是其产品详情：
基本信息
品牌：GE Fanuc
型号：IC670MDL640
产品类型：离散输入模块
适用系统：GE 90-30系列可编程逻辑控制器（PLC）
技术参数
输入点数：16个独立输入通道
输入电压范围：0至30VDC
额定电压：24VDC
输入电流：额定电压下每点7.5mA
输出电压范围：0至30VDC
输出电流：每点10mA
电源电压：24VDC
功耗：75至83mA
工作温度范围：-40°C至+70°C
存储温度范围：-40°C至+85°C
湿度：5%至95%RH，无凝结
振动：5g，峰峰值，随机
冲击：30g，半正弦，持续时间11毫秒
EMC：符合IEC 61000-4-2、IEC 61000-4-3和IEC 61000-4-6标准
功能特点
高密度：在紧凑的封装中提供16个输入通道，节省控制面板空间。
多功能输入逻辑：支持正逻辑和负逻辑接线配置，适合与各种现场设备连接。
坚固的结构：设计用于承受工业应用的恶劣环境，具有较强的抗干扰能力。
易于安装维护：可使用GE Fanuc Proficy HMI软件轻松安装和配置，每个输入通道都有LED指示灯，便于查看输入状态，且模块支持热插拔，维护方便。
应用领域
广泛应用于输送系统、包装机、物料搬运系统、暖通空调系统、安全系统等工业场景，用于监控外部现场设备，如开关、传感器和按钮的状态，并将其电压电平转换为PLC可以读取的数字信号。
The GE IC670MDL640 is a discrete input module manufactured by GE Fanuc,belonging to the Field Control series,and is mainly used in industrial automation control systems.The following are the product details:Basic Information Brand:GE Fanuc Model:IC670MDL640 Product Type:Discrete Input Module Applicable Systems:GE 90-30 Series Programmable Logic Controllers(PLCs)Technical Specifications Number of Input Points:16 independent input channels Input Voltage Range:0 to 30VDC Rated Voltage:24VDC Input Current:7.5mA per point at rated voltage Output Voltage Range:0 to 30VDC Output Current:10mA per point Power Supply Voltage:24VDC Power Consumption:75 to 83mA Operating Temperature Range:-40°C to+70°C Storage Temperature Range:-40°C to+85°C Humidity:5%to 95%RH,non-condensing Vibration:5g,peak-to-peak,random Shock:30g,half-sine,duration 11 ms EMC:Compliant with IEC 61000-4-2,IEC 61000-4-3 and IEC 61000-4-6 Standards
Features
High Density:Provides 16 input channels in a compact package,saving control panel space.
Multi-functional Input Logic:Supports positive and negative logic wiring configurations,suitable for connection to a variety of field devices.
Rugged Construction:Designed to withstand harsh industrial environments,with strong anti-interference capabilities.
Easy Installation and Maintenance:Easily installed and configured using GE Fanuc Proficy HMI software.Each input channel has LED indicators for easy viewing of input status,and the module supports hot-swapping for convenient maintenance.
Applications
Widely used in industrial scenarios such as conveyor systems,packaging machines,material handling systems,HVAC systems,and safety systems to monitor the status of external field devices such as switches,sensors,and buttons,converting their voltage levels into digital signals that can be read by the PLC.
