描述
GE IC694ALG392是GE Fanuc Automation生产的一款模拟量输出模块，属于PACSystems RX3i系列。以下是其产品详情：
通道数量：8路单端输出。
输出类型：电流或电压。
输出范围：电压为0-10V（单极性）、-10V至+10V（双极性）；电流为0-20mA、4-20mA。
分辨率：16位（电压模式LSB=0.3125mV，电流模式LSB=0.5–0.625μA）。
更新速率：8ms。
精度：±0.25%满量程（25°C典型值），±1%。
功耗：5VDC背板电源110mA；24VDC外部电源315mA。
工作电压：外部电源电压范围为20-30VDC，内部由PLC背板提供+5VDC电源。
隔离情况：现场到背板（光学）和框架接地之间隔离，持续250VAC；1500VDC持续1分钟。
安装方式：DIN导轨安装。
认证：通过了UL、UL HAZLOC、Zone 2 CE、ATEX C1D2等多个认证机构的认证。
该模块主要用于将数字信号转换为模拟信号，以便控制外部设备，如阀门、电机等，广泛应用于工业自动化、过程控制、机器人控制等领域。
The GE IC694ALG392 is an analog output module manufactured by GE Fanuc Automation and is part of the PACSystems RX3i series.Product details are as follows:
Number of channels:8 single-ended outputs.
Output type:Current or voltage.
Output range:Voltage:0-10V(unipolar),-10V to+10V(bipolar);Current:0-20mA,4-20mA.
Resolution:16 bits(voltage mode LSB=0.3125mV,current mode LSB=0.5–0.625μA).
Update rate:8ms.
Accuracy:±0.25%of full scale(typical at 25°C),±1%.
Power consumption:110mA from 5VDC backplane power supply;315mA from 24VDC external power supply.Operating Voltage:External power supply voltage range is 20-30VDC;internal power is provided by the PLC backplane.
Isolation:Field isolation to the backplane(optical)and frame ground,250VAC continuous;1500VDC for 1 minute.
Mounting Method:DIN rail mount.
Certification:Certified by multiple certification agencies,including UL,UL HAZLOC,Zone 2 CE,and ATEX C1D2.
This module converts digital signals into analog signals for controlling external devices such as valves and motors.It is widely used in industrial automation,process control,and robotics.
