GE IC694MDL740是一款专为GE Fanuc系列PLC设计的离散输出模块，属于PACSystems RX3i系列。以下是其产品详情：
输出通道：共有16个输出点，分为两组，每组8个。每组有一个共用的电源输出端。
输出特性：输出类型为12/24VDC正逻辑，每点输出电流为0.5A。它向负载提供的源电流来自用户公共端或者正电源总线，输出装置连接在负电源总线和模块端子之间。
负载兼容性：输出特性兼容多种负载设备，如电动机启动器、螺线管、指示器等。
状态指示：每个输出点都有单独编号的发光二极管，用于显示该点的状态（ON/OFF）。
电气隔离：现场侧到背板（光电）和框架地之间的隔离电压为250VAC连续、1500VAC持续1分钟，输出点之间的隔离电压也为250VAC连续、1500VAC持续1分钟。
工作电压：额定电压为12/24VDC。
模块特点：具有快速响应的特点，输出延迟极低，适合对实时控制要求高的应用。此外，该模块兼容性强，与GE所有主要PLC系列兼容，且采用模块化设计，安装和更换非常简单，降低了维护成本。
应用领域：可广泛应用于各类工业自动化控制系统中，如机械手臂、生产线、HVAC系统等，在制造业、建筑自动化、能源管理等行业都有重要应用。
The GE IC694MDL740 is a discrete output module designed for GE Fanuc PLCs,part of the PACSystems RX3i series.The following are product details:
Output Channels:16 output points,divided into two groups of 8.Each group has a shared power output.
Output Characteristics:12/24VDC positive logic output,with a current of 0.5A per output point.The output current supplied to the load comes from the user common or the positive power bus.The output device is connected between the negative power bus and the module terminals.
Load Compatibility:The output characteristics are compatible with a variety of load devices,such as motor starters,solenoids,and indicators.
Status Indicator:Each output point has a uniquely numbered LED to indicate its status(ON/OFF).Electrical Isolation:The isolation voltage between the field side and the backplane(photoelectric)and chassis ground is 250VAC continuous,1500VAC for 1 minute.The isolation voltage between output points is also 250VAC continuous,1500VAC for 1 minute.
Operating Voltage:Rated voltage is 12/24VDC.
Module Features:Featuring fast response and extremely low output latency,it is suitable for applications requiring high real-time control.Furthermore,the module is highly compatible with all major GE PLC series.Its modular design simplifies installation and replacement,reducing maintenance costs.
Applications:It can be widely used in various industrial automation control systems,such as robotic arms,production lines,and HVAC systems.It has important applications in manufacturing,building automation,energy management,and other industries.
