描述
GE IC697ACC723是通用电气公司生产的接地故障继电器模块，属于Mark I或Mark II系列燃气和蒸汽轮机控制器。以下是其产品详情：
基本功能：该模块主要用于检测和处理接地故障，确保燃气和蒸汽轮机系统的安全运行。
组成结构：由两个集成电路和四个晶体管组成，这两个电路都是四比较器，具有低功耗和低失调电压。此外，模块上还有四个发光二极管（CR1至CR4）用于指示相关状态，以及32个跳线开关，每个跳线为用户提供了两种方式来完成每个电路的选择。
机械特性：模块有一个直角公连接器，编号为218A4637P2，板子另一边有二十五个金属销钉，引脚下方有从十到五十的编号，用于将电路板连接到Mark I/II框架的接线。模块表面还有四个继电器。
工作环境：Mark I和Mark II系列控制器可在低至-50°C的温度下以及从海上到远程管道站的各种环境中工作。
The GE IC697ACC723 is a ground-fault relay module manufactured by General Electric and is part of the Mark I or Mark II series of gas and steam turbine controllers.The following are product details:
Basic Function:This module is primarily used to detect and handle ground faults,ensuring safe operation of gas and steam turbine systems.
Construction:It consists of two integrated circuits and four transistors.Both circuits are quad comparators with low power consumption and low offset voltage.In addition,the module features four LEDs(CR1 to CR4)for status indication and 32 jumper switches,each providing two user-selectable circuits.
Mechanical Features:The module has a right-angle male connector,numbered 218A4637P2.Twenty-five metal pins are located on the other side of the board,numbered 10 to 50 below,for connecting the board to the Mark I/II frame.Four relays are also located on the module’s surface.Operating Environment:Mark I and Mark II Series controllers can operate in temperatures as low as-50°C and in a variety of environments from offshore to remote pipeline stations.
