描述
GE IC697BEM713是GE Fanuc 90-70系列的总线发射模块（BTM）。以下是其产品详情：
功能：允许从主CPU机架扩展到最多7个额外的IC697 PLC机架，以增加系统能够处理的输入和输出数量，适用于离散控制、模拟控制、运动控制、机器人技术和过程控制等工业自动化应用。
技术参数
接口：具有2个连接器，顶部的连接器用于与编程设备接口，底部的连接器用于通过总线接收模块进行级联配置。
数据传输速率：有效数据速率为500KB/秒。
电缆允许距离：最长为50英尺（约15米）。
功耗：约5瓦特。
工作温度范围：0°C至60°C。
存储温度范围：-40°C至85°C。
湿度：5%至95%非冷凝。
配置方式：可通过MS-DOS或Windows编程软件进行配置，无需使用DIP开关。
状态指示：配备3个LED指示灯，可分别显示模块状态、编程器端口状态和扩展端口状态。
安装要求：占用一个插槽，不能安装在插槽1，必须安装在任何IC697中断源模块的右侧。
The GE IC697BEM713 is a bus transmitter module(BTM)for the GE Fanuc 90-70 series.Product details are as follows:
Function:Allows expansion from a main CPU rack to up to seven additional IC697 PLC racks,increasing the number of inputs and outputs the system can handle.It is suitable for industrial automation applications such as discrete control,analog control,motion control,robotics,and process control.
Technical Specifications
Interface:Features two connectors:a top connector for interfacing with programming devices and a bottom connector for cascading configurations with bus receiver modules.
Data Transfer Rate:Effective data rate of 500KB/s.
Cable Distance:Up to 50 feet(approximately 15 meters).
Power Consumption:Approximately 5 watts.
Operating Temperature Range:0°C to 60°C.
Storage Temperature Range:-40°C to 85°C.
Humidity:5%to 95%non-condensing.Configuration:Can be configured via MS-DOS or Windows programming software,eliminating the need for DIP switches.
Status Indicator:Equipped with three LED indicators to display module status,programmer port status,and expansion port status.
Installation Requirements:Occupies one slot and cannot be installed in slot 1.Must be installed to the right of any IC697 interrupt source module.
