描述
主要产品详情和功能
PMC尺寸：该模块设计用于插入PMC插槽，PMC插槽是用于高性能I/O的标准夹层卡尺寸。这使得它可以轻松与各种主机板集成，例如单板计算机(SBC)或其他具有可用PMC插槽的载卡。
串行ATA(SATA)硬盘驱动器：其核心功能是使用串行ATA接口提供存储。这允许与板载硬盘或固态硬盘进行高速数据传输（最高可达SATA II 300 MB/s或3.0 Gb/s）。
存储容量：部件号中的“282000”通常表示具体的存储容量。根据PMC-0247RC系列的常见配置，这可能表示160 GB旋转介质（硬盘驱动器）版本。其他型号还提供容量高达250 GB的HDD和容量高达16 GB、32 GB或64 GB的固态硬盘(SSD)。
企业级存储：专为高要求嵌入式计算应用而设计，具备以下特性：
可靠性：可承受连续运行（24×7，每年8760小时）。
坚固性：可提供增强的抗冲击和抗震性能，并可在极端海拔高度下运行。
长产品生命周期：特定旋转介质的HDD产品生命周期通常为5年，这对于长期工业项目至关重要。
PCI-X接口支持：支持32/64位、最高133 MHz的PCI-X接口，可与主机系统进行高带宽通信。
通用信号支持：可安装在任何可用的3.3V或5.0V PMC站点，提供灵活的集成。
BIOS扩展：支持可编程外部闪存进行BIOS扩展。
符合RoHS标准：PMC-0247RC中的“RC”表示其符合RoHS（有害物质限制指令）。
通用规格（PMC-0247RC系列通用）
外形尺寸：PMC（PCI接口卡）
功能：串行ATA硬盘模块
接口：SATA II（300 MB/s或3.0 Gb/s）
支持的驱动器：2.5英寸硬盘(HDD)或固态硬盘(SSD)
容量：HDD最高250 GB，SSD容量可选。
PCI接口：32/64位，133 MHz PCI-X
工作温度（HDD）：+5°C至+55°C（标准工作），+5°C至+40°C（扩展工作）
工作温度（SSD）：0°C至+70°C
存储温度：-40°C至+85°C
相对湿度：5%至95%，无凝结
电源要求：通过主板上的PMC接口供电。
符合法规：CE标志（EN55024、EN55022 A类、EN61000系列）、FCC第15部分A类、ICES-003 A类。
操作系统支持：通常支持Windows 2000、Windows XP和Red Hat Linux Enterprise 4.0。
Key Product Details and Functions
PMC Form Factor:The module is designed to fit into a PMC slot,which is a standard mezzanine card form factor for high-performance I/O.This allows it to be easily integrated with a variety of host boards,such as single board computers(SBCs)or other carrier cards that have an available PMC site.
Serial ATA(SATA)Hard Disk Drive:Its core function is to provide storage using the Serial ATA interface.This allows for high-speed data transfer(up to SATA II 300 MB/s or 3.0 Gb/s)to and from the onboard hard disk or solid-state drive.
Storage Capacity:The”282000″in the part number often indicates a specific storage capacity.Based on common configurations for the PMC-0247RC series,this could denote a 160 GB rotating media(Hard Disk Drive)version.Other variants also exist with capacities up to 250 GB for HDDs,and Solid State Drives(SSDs)in capacities like 16 GB,32 GB,or 64 GB.
Enterprise-Class Storage:Designed for demanding embedded computing applications,implying features like:
Reliability:Built to withstand continuous operation(24×7,8760 hours/year).
Robustness:Options for extended shock and vibration resistance,and extreme altitude operation.
Long Product Lifecycle:Often with a 5-year HDD Product Lifecycle for specified rotating media,which is crucial for long-term industrial projects.
PCI-X Interface Support:It supports a 32/64-bit,133 MHz maximum PCI-X interface,allowing for high-bandwidth communication with the host system.
Universal Signaling Support:Can be installed in any available 3.3V or 5.0V PMC site,offering flexibility in integration.
BIOS Expansion:Supports a programmable external flash for BIOS expansion.
RoHS Compliant:The”RC”in PMC-0247RC indicates that it is RoHS(Restriction of Hazardous Substances)compliant.
General Specifications(Common for PMC-0247RC series)
Form Factor:PMC(PCI Mextures Card)
Function:Serial ATA Hard Disk Drive Module
Interface:SATA II(300 MB/s or 3.0 Gb/s)
Supported Drives:2.5-inch Hard Disk Drives(HDD)or Solid State Drives(SSD)
Capacity:Up to 250 GB for HDD,various smaller capacities for SSDs.
PCI Interface:32/64-bit,133 MHz PCI-X
Operating Temperature(HDD):+5°C to+55°C(standard operation),+5°C to+40°C(extended duty)
Operating Temperature(SSD):0°C to+70°C
Storage Temperature:-40°C to+85°C
Relative Humidity:5%to 95%,non-condensing
Power Requirements:Supplied through the PMC site connectors on the host board.
Regulatory Compliance:CE Mark(EN55024,EN55022 Class A,EN61000 series),FCC Part 15 Class A,ICES-003 Class A.
Operating System Support:Often includes support for Windows 2000,Windows XP,and Red Hat Linux Enterprise 4.0.
