描述
GE VMIVME-4116是通用电气（GE）生产的高性能工业控制模块，属于VMIC Megamodule系列，采用VMEbus接口标准。具体详情如下：
技术参数：
通道数量：8个独立通道。
分辨率：16位。
输出电压范围：±10V。
采样率：高达几百千赫（通常在几MHz范围内）。
电源要求：+5V。
工作温度范围：-40°C至+85°C。
尺寸：233mm×167mm×22mm。
重量：约0.5公斤。
接口类型：VMEbus。
产品特点：
高精度：采用16位DAC，提供±0.1%的精度和±0.05%的线性度。
快速响应：更新速率为1kHz，确保快速响应，稳定时间为10µs内达到±1/2LSB精度。
灵活性强：通过软件可配置输出电压范围、增益等参数。
可靠性高：采用工业级元器件，内置隔离和滤波功能，确保长期稳定运行。
可扩展性好：支持与其他VME模块组合使用，实现更复杂的系统功能。
功能作用：主要作用是将数字信号转换为模拟信号，用于驱动模拟设备，如电机和阀门等。还支持测试测量、数据采集和科学研究中的实验数据输出、信号模拟等功能。
应用领域：广泛应用于工业自动化、测试测量、科学研究、医疗设备、航空航天等领域，可用于过程控制、伺服驱动、信号发生器、飞行控制等场景。
The GE VMIVME-4116 is a high-performance industrial control module manufactured by General Electric(GE).It belongs to the VMIC Megamodule series and utilizes the VMEbus interface standard.Specific details are as follows:
Technical Parameters:
Number of Channels:8 independent channels.
Resolution:16 bits.
Output Voltage Range:±10V.
Sampling Rate:Up to several hundred kHz(typically in the MHz range).
Power Supply:+5V.
Operating Temperature Range:-40°C to+85°C.
Dimensions:233mm×167mm×22mm.
Weight:Approximately 0.5 kg.
Interface Type:VMEbus.
Features:
High Accuracy:Utilizes a 16-bit DAC,providing±0.1%accuracy and±0.05%linearity.
Fast Response:A 1kHz update rate ensures fast response,with a settling time of 10µs to achieve±1/2LSB accuracy.High Flexibility:Parameters such as output voltage range and gain are configurable via software.
High Reliability:Utilizing industrial-grade components and built-in isolation and filtering ensures long-term stable operation.
Excellent Scalability:It can be combined with other VME modules to achieve more complex system functions.
Function:It primarily converts digital signals into analog signals for driving analog devices such as motors and valves.It also supports experimental data output and signal simulation for test and measurement,data acquisition,and scientific research.
Application Areas:It is widely used in industrial automation,test and measurement,scientific research,medical equipment,aerospace,and other fields,and can be used in process control,servo drives,signal generators,flight control,and other scenarios.
