描述
主要产品详情和功能
反射内存接口：VMIVME-5565的核心功能是实现反射内存（通常称为共享内存或反射内存）。该技术在多个独立计算机系统（节点）之间创建共享数据空间。当数据写入一个节点的反射内存时，会自动快速地“反射”（复制）到所有其他连接节点的反射内存中。
VMEbus兼容性：它是一个VMEbus模块，这意味着它可以直接插入VMEbus背板。VMEbus是一种强大的高性能总线标准，因其多处理能力和可靠性而广泛用于工业控制、航空航天、国防和科学应用。
高速数据交换：反射内存以其极低的延迟和高吞吐量而闻名。这允许在系统之间实现确定性（可预测）和实时数据共享，使其成为对时间要求严格的应用的理想选择。
全局数据一致性：确保所有连接节点都拥有相同的、同步的共享数据副本。这简化了实时应用程序的编程，因为开发人员无需管理复杂的网络协议或同步机制。
容错/冗余：反射内存的本质就支持冗余。如果一个节点发生故障，其他节点仍可继续使用共享数据运行，从而提高系统弹性。
处理器间通信(IPC)：它可作为直接的内存到内存链路，促进多个处理器或控制系统之间的高速通信。
32位P1/P2 VME接口：该模块支持32位VMEbus接口，提供宽阔的数据路径以实现高效传输。
型号规格：
VMIVME-5565：这是产品系列的名称。
010000：此部分数字通常表示具体的配置选项，例如内存大小（例如，256KB、512KB、1MB、2MB、4MB共享内存）。“010000”可能表示1MB配置，但具体数据手册会确认这一点。
332-015565-010000 P：这是完整的部件号或装配号，包括修订版或制造代码。
“P”：通常表示适用于恶劣环境或其他特定制造变化的保形涂层版本。
通用规格（适用于VMIVME-5565系列）
总线接口：VMEbus（32位数据、32位地址、A32/A24/A16、D32/D16/D08）
反射内存大小：可配置，通常从256 KB到4 MB或更大。
数据速率：极高的吞吐量，在数十到数百MB/s范围内。
延迟：极低的延迟，通常在微秒级。
数据完整性：奇偶校验或ECC（纠错码）用于确保数据完整性。
光纤接口：与其他反射存储器节点的连接通常通过光纤电缆进行，提供电气隔离和长距离传输能力。
功耗：因配置而异，但通常在个位数瓦范围内。
工作温度：工业级，通常为0°C至+70°C，部分型号支持更宽的温度范围。
外形尺寸：单槽6U VMEbus模块。
典型应用
GE VMIVME-5565-010000对于需要确定性、高速数据传输和处理器间通信的应用至关重要：
实时仿真：连接多个仿真器或硬件在环(HIL)系统。
工业控制系统：在大型SCADA或DCS系统中进行高速数据交换，协调多个PLC或控制器。
航空航天与国防：飞行模拟器、武器系统控制、雷达系统以及指挥与控制应用。
测试与测量：在复杂的试验台中同步多个数据采集和控制单元。
核电站：关键控制和安全系统。
高速数据采集：从多个传感器收集同步数据。
Key Product Details and Functions
Reflection Memory Interface:The core function of the VMIVME-5565 is to implement Reflection Memory(often called Shared Memory or Reflective Memory).This technology creates a shared data space across multiple independent computer systems(nodes).When data is written to the Reflection Memory on one node,it’s automatically and rapidly”reflected”(copied)to the Reflection Memory on all other connected nodes.
VMEbus Compatibility:It’s a VMEbus module,meaning it plugs directly into a VMEbus backplane.The VMEbus is a robust,high-performance bus standard commonly used in industrial control,aerospace,defense,and scientific applications due to its multiprocessing capabilities and reliability.
High-Speed Data Exchange:Reflection Memory is known for its extremely low latency and high throughput.This allows for deterministic(predictable)and real-time data sharing between systems,making it ideal for applications where timing is critical.
Global Data Consistency:It ensures that all connected nodes have an identical,synchronized copy of the shared data.This simplifies programming for real-time applications,as developers don’t need to manage complex network protocols or synchronization mechanisms.
Fault Tolerance/Redundancy:The nature of Reflection Memory inherently supports redundancy.If one node fails,the others continue to operate with the shared data,contributing to system resilience.
Inter-Processor Communication(IPC):It facilitates high-speed communication between multiple processors or control systems,acting as a direct memory-to-memory link.
32-bit P1/P2 VME Interface:The module supports the 32-bit VMEbus interface,providing a wide data path for efficient transfers.
Model Specifics:
VMIVME-5565:This is the product family designation.
010000:This part of the number usually denotes specific configuration options,such as memory size(e.g.,256KB,512KB,1MB,2MB,4MB of shared memory).The”010000″might indicate a 1MB configuration,but specific datasheets would confirm this.
332-015565-010000 P:This is the full part number or assembly number,including revision or manufacturing codes.
“P”:Often indicates a conformal coated version for harsh environments or other specific manufacturing variations.
General Specifications(Common for VMIVME-5565 series)
Bus Interface:VMEbus(32-bit data,32-bit address,A32/A24/A16,D32/D16/D08)
Reflection Memory Size:Configurable,typically from 256 KB up to 4 MB or more.
Data Rate:Very high throughput,in the range of tens to hundreds of MB/s.
Latency:Extremely low latency,often in the order of microseconds.
Data Integrity:Parity or ECC(Error Correction Code)for data integrity.
Optical Fiber Interface:Connection to other Reflection Memory nodes is typically via fiber optic cables,providing electrical isolation and long-distance capabilities.
Power Consumption:Varies by configuration,but typically in the single-digit watt range.
Operating Temperature:Industrial grade,often 0°C to+70°C,with some variants supporting extended temperatures.
Form Factor:Single-slot 6U VMEbus module.
Typical Applications
The GE VMIVME-5565-010000 is critical in applications requiring deterministic,high-speed data transfer and inter-processor communication:
Real-time Simulation:Connecting multiple simulators or hardware-in-the-loop(HIL)systems.
Industrial Control Systems:High-speed data exchange in large-scale SCADA or DCS systems,coordinating multiple PLCs or controllers.
Aerospace and Defense:Flight simulators,weapon systems control,radar systems,and command and control applications.
Test and Measurement:Synchronizing multiple data acquisition and control units in complex test stands.
Nuclear Power Plants:Critical control and safety systems.
High-Speed Data Acquisition:Collecting synchronized data from many sensors.
