描述
产品简要说明
GE DS200PCCAG6A是通用电气（GE）推出的工业控制模块，核心功能包括：
电源管理：支持24VDC输入，兼容正逻辑输出与多类型负载控制
智能保护：内置短路检测与电子保护机制，实时监控模块状态
工业级环境适应：通过宽温设计与抗干扰认证，适用于严苛工业场景
产品详细说明
1.硬件架构与核心功能
电源与输出特性：
正逻辑输出：通过用户共用端或正电源总线提供源电流，输出端连接至负电源总线与负载
兼容负载类型：支持电动机启动器、电磁阀、指示灯等工业设备
状态指示：每个输出点配备绿色LED，通过两行八列布局显示开关状态（A1-A8与B1-B8）
保护机制：
短路检测：红色LED（F）实时反馈电子短路保护动作
无熔断器设计：依赖电子电路实现过流保护，避免机械熔断器老化问题
2.通信与扩展能力
接口配置：
串口通信：通过9针RS232接口与主控制器（如2301D/2301D-EC控制器）连接
模块化安装：兼容RX3i系统I/O插槽，支持多模块扩展
数据交互：
状态反馈：输出端LED状态可远程监控，简化故障诊断流程
3.工业级可靠性设计
环境耐受性：
宽温运行：-40℃至85℃连续工作（参考同系列DS200PCCAG6ADB的参数）
抗干扰能力：符合工业电磁兼容标准（如EN 61000-6-4）
冗余与安全：
电源冗余：支持双路24VDC输入，切换时间＜50ms
故障隔离：短路保护机制可切断故障回路，避免系统级宕机
技术规格:GE DS200PCCAG6A
参数项规格描述
输入电压24VDC
输出逻辑正逻辑（源电流输出）
通信接口9针RS232串口
Product brief description
GE DS200PCCAG6A is an industrial control module launched by General Electric(GE),with core functions including:
Power management:Supports 24VDC input,compatible with positive logic output and multi-type load control
Intelligent protection:built-in short-circuit detection and electronic protection mechanism,real-time monitoring of module status
Industrial-grade environmental adaptation:passed wide temperature design and anti-interference certification,suitable for rigorous industrial scenarios
Product details
1.Hardware architecture and core functions
Power and output characteristics:
Positive logic output:The source current is provided through the user’s common terminal or the positive power bus,and the output terminal is connected to the negative power bus and the load.
Compatible load type:Supports industrial equipment such as motor starters,solenoid valves,indicator lights,etc.
Status indication:Each output point is equipped with green LED,and the switch status is displayed through two rows and eight columns layout(A1-A8 and B1-B8)
Protection mechanism:
Short circuit detection:Red LED(F)real-time feedback electronic short circuit protection action
Fuseless design:rely on electronic circuits to achieve overcurrent protection to avoid aging of mechanical fuses
2.Communication and expansion capabilities
Interface configuration:
Serial port communication:Connect to the main controller(such as 2301D/2301D-EC controller)through the 9-pin RS232 interface
Modular installation:compatible with RX3i system I/O slots,supports multi-module expansion
Data interaction:
Status feedback:The LED status at the output terminal can be monitored remotely,simplifying the fault diagnosis process
3.Industrial-grade reliability design
Environmental tolerance:
Wide temperature operation:continuous operation from-40℃to 85℃(refer to the parameters of the same series DS200PCCAG6ADB)
Anti-interference ability:comply with industrial electromagnetic compatibility standards(such as EN 61000-6-4)
Redundancy and security:
Power redundancy:supports dual 24VDC input,switching time<50ms
Fault isolation:The short circuit protection mechanism can cut off the fault circuit and avoid system-level downtime
Technical Specifications:GE DS200PCCAG6A
Parameters Specification Description
Input voltage 24VDC
Output logic Positive logic(source current output)
Communication interface 9-pin RS232 serial port
