描述
产品简要说明
General Electric DS200VPBLG1AFF是通用电气（GE）为工业自动化系统设计的通信模块，核心功能包括：
工业网络兼容性：支持EtherNet/IP、Profinet及Modbus TCP协议，适配GE Speedtronic系统生态
冗余安全机制：内置双通道通信备份，故障切换时间＜10ms
宽温域运行：-40℃至70℃工作温度，防护等级IP65（选配）
产品详细说明
1.硬件架构与核心组件
模块化设计：
采用VME/PLC标准背板总线架构，兼容GE PACSystems系列控制器
支持热插拔扩展，单模块提供4路独立工业以太网接口（RJ45）
抗干扰设计：
输入/输出端采用光电隔离技术，耐受工业现场电磁干扰（EMI等级达IEC 61000-4-2 Level 4）
工作温度范围-40℃～70℃，防护等级IP65（选配）
2.功能特性与工业适配性
智能通信管理：
支持多协议动态切换，可同时运行EtherNet/IP与Profinet协议
内置流量控制算法，数据传输延迟≤2ms
安全防护机制：
双通道冗余设计，主备通道实时同步数据，故障切换无缝
内置自检功能，实时监测模块温度、电压及通信状态
技术规格:General Electric DS200VPBLG1AFF
参数项规格描述
通信接口4×RJ45工业以太网接口（支持EtherNet/IP、Profinet、Modbus TCP）
带宽100Mbps（每通道）
协议兼容性EtherNet/IP、Profinet、Modbus TCP
背板总线VME/PLC
功耗180mA（5V电源）
工作温度-40℃～70℃
防护等级IP65（选配）
物理尺寸130mm×100mm×40mm
Product brief description
General Electric DS200VPBLG1AFF is a communication module designed by General Electric(GE)for industrial automation systems.The core functions include:
Industrial network compatibility:Supports EtherNet/IP,Profinet and Modbus TCP protocols,and adapts to GE Speedtronic system ecosystem
Redundant security mechanism:built-in dual-channel communication backup,failover time<10ms
Wide temperature range operation:-40℃to 70℃operating temperature,protection level IP65(optional)
Product details
1.Hardware architecture and core components
Modular design:
Adopt VME/PLC standard backplane bus architecture,compatible with GE PACSystems series controllers
Supports hot-swap extension,single module provides 4 independent industrial Ethernet interfaces(RJ45)
Anti-interference design:
The input/output terminal adopts photoelectric isolation technology to withstand industrial field electromagnetic interference(EMI level up to IEC 61000-4-2 Level 4)
Working temperature range-40℃~70℃,protection level IP65(optional)
2.Functional characteristics and industrial adaptability
Intelligent communication management:
Supports dynamic switching of multi-protocols,and can run EtherNet/IP and Profinet protocols simultaneously
Built-in flow control algorithm,data transmission delay≤2ms
Safety protection mechanism:
Dual-channel redundant design,real-time synchronization of data from the main and backup channels,seamless failure-switching
Built-in self-test function to monitor the module temperature,voltage and communication status in real time
Technical Specifications:General Electric DS200VPBLG1AFF
Parameters Specification Description
Communication interface 4×RJ45 industrial Ethernet interface(supports EtherNet/IP,Profinet,Modbus TCP)
Bandwidth 100Mbps(per channel)
Protocol Compatibility EtherNet/IP,Profinet,Modbus TCP
Backplane bus VME/PLC
Power consumption 180mA(5V power supply)
Working temperature-40℃~70℃
Protection level IP65(optional)
Physical dimensions:130mm×100mm×40mm
