描述
产品简要说明
MAGNETEK XLTX 195-52176-1000是一款专为工业过程控制设计的高精度温度变送器模块，核心特性包括：
宽量程支持：兼容热电偶（K/J/S型）与热电阻（Pt100/Pt1000）
抗干扰设计：EMC等级Class B，适应电磁干扰环境
智能补偿算法：线性化误差≤0.1%FS
产品详细说明
1.核心功能架构
信号采集单元：
采用双通道隔离放大器，信噪比≥100dB
内置冷端补偿电路（热电偶模式），补偿精度±0.5℃
数据处理单元：
32位微控制器实时处理信号，采样速率100Hz
支持PID控制算法（可选）
2.硬件特性
接口配置：
输入：4线制热电阻/热电偶输入
输出：4-20mA模拟量+MODBUS RTU通信
环境适应性：
工作温度范围：-40℃至85℃（宽温版本）
防护等级IP67（防尘防水）
技术规格:MAGNETEK XLTX 195-52176-1000
参数项规格描述
输入类型热电偶（K/J/S）/热电阻（Pt100/Pt1000）
精度±0.2℃（热电偶），±0.1%FS（热电阻）
输出范围4-20mA（可定制0-10V）
通信协议MODBUS RTU（RS485接口）
供电电压24V DC±10%
核心价值与性能亮点
1.多协议兼容性
优势：支持MODBUS RTU与HART协议混合组网，适配不同控制系统。
2.极端环境适应性
案例：在钢铁厂高炉监测中，连续运行5年无漂移，环境温度达120℃。
3.智能诊断功能
功能：
实时监测传感器断线、短路故障
自动切换冗余输入通道（可选）
Product brief description
MAGNETEK XLTX 195-52176-1000 is a high-precision temperature transmitter module designed for industrial process control,with core features including:
Wide range support:compatible with thermocouple(K/J/S type)and thermal resistor(Pt100/Pt1000)
Anti-interference design:EMC grade Class B,adapted to electromagnetic interference environment
Intelligent compensation algorithm:linearization error≤0.1%FS
Product details
1.Core functional architecture
Signal acquisition unit:
Using dual-channel isolated amplifier,signal-to-noise ratio≥100dB
Built-in cold-end compensation circuit(thermocouple mode),compensation accuracy±0.5℃
Data processing unit:
32-bit microcontroller processes signals in real time,sampling rate of 100Hz
Supports PID control algorithm(optional)
2.Hardware features
Interface configuration:
Input:4-wire heating resistor/thermocouple input
Output:4-20mA analog quantity+MODBUS RTU communication
Environmental adaptability:
Operating temperature range:-40℃to 85℃(wide temperature version)
Protection level IP67(dust-proof and waterproof)
Technical Specifications:MAGNETEK XLTX 195-52176-1000
Parameters Specification Description
Input type Thermocouple(K/J/S)/Thermal resistance(Pt100/Pt1000)
Accuracy±0.2℃(thermocouple),±0.1%FS(thermoresistor)
Output range 4-20mA(customizable 0-10V)
Communication Protocol MODBUS RTU(RS485 Interface)
Supply voltage 24V DC±10%
Core Valuesand Performance Highlights
1.Multi-protocol compatibility
Advantages:Supports hybrid networking of MODBUS RTU and HART protocols,and is adapted to different control systems.
2.Extreme environmental adaptability
Case:During the monitoring of blast furnaces in the steel plant,the continuous operation was operated for 5 years without drift,and the ambient temperature reached 120℃.
3.Intelligent diagnostic function
Function:
Real-time monitoring of sensor disconnection and short circuit faults
Automatically switch redundant input channels(optional)
