描述
Hima F7133是一款4通道配电模块，属于Hima Himatrix系列，主要用于为安全相关的设备提供可靠的电源。以下是其产品详情：
基本信息
品牌：Hima
型号：F7133
产品类型：配电模块
原产国：德国
通道数：4
安装方式：DIN导轨安装
防护等级：IP20
技术参数
输入电压：24VDC
输出电压：24VDC
输出电流：每通道4A
保险丝额定值：每通道2A
最大保险丝：4A慢熔
切换时间：约100ms（继电器）
继电器触点负载能力：30V/4A（连续负载）
工作温度：0℃至50℃
相对湿度：5%至95%
功能特点
安全等级高：符合SIL 3认证（根据IEC 61508），适用于安全关键型应用。
独立保护：为每个通道提供独立的熔断/PD保护，防止故障扩散。
状态监控：模块有4个内置微型保险丝，每个保险丝关联一个LED，通过LED实时显示保险丝状态，便于快速识别和处理故障。
模块化设计：易于安装和维护。
The Hima F7133 is a 4-channel power distribution module from the Hima Himatrix series,designed to provide reliable power to safety-related equipment.Below are the product details:
Basic Information
Brand:Hima
Model:F7133
Product Type:Power Distribution Module
Country of Origin:Germany
Number of Channels:4
Mounting Method:DIN Rail
Protection Rating:IP20
Technical Parameters
Input Voltage:24VDC
Output Voltage:24VDC
Output Current:4A per Channel
Fuse Rating:2A per Channel
Maximum Fuse:4A slow-blow
Switching Time:Approximately 100ms(relay)
Relay Contact Load Capacity:30V/4A(continuous duty)
Operating Temperature:0°C to 50°C
Relative Humidity:5%to 95%
Features
High Safety Level:SIL 3 certified(according to IEC 61508),suitable for safety-critical applications.Independent Protection:Each channel is provided with independent fuse/PD protection to prevent fault propagation.
Status Monitoring:The module has four built-in microfuses,each associated with an LED.The LED displays the fuse status in real time,making it easy to quickly identify and resolve faults.
Modular Design:Easy to install and maintain.
