描述
1.产品定位与分类
HIMA X-FAN 1803是HIMA安全控制系统中的风扇模块，属于H41q/H51q系列安全控制器的可选配件，主要用于散热与系统冗余设计。其核心作用包括：
主动散热：为控制器内部电子元件（如CPU、通信模块）提供强制风冷，确保在高温环境（如化工、油气行业）下稳定运行。
冗余支持：可与备用风扇模块配合，实现N+1冗余，避免单点故障导致系统停机。
环境适应性：针对防爆区域（Ex d/Ex i）或高湿度/粉尘环境优化设计，符合ATEX、IECEx等国际认证。
2.关键技术参数
2.1基础规格
参数项详细说明
适用系统HIMA H41q/H51q系列安全控制器（如F8627A、F8650A等型号）
尺寸标准19英寸机架安装（高度1U，宽度与控制器匹配）
重量约1.5kg（含风扇组件与外壳）
接口类型专用连接器（与控制器背板直接对接，无需额外线缆）
2.2风扇性能
参数项详细说明
风扇数量双风扇设计（独立控制，支持冗余切换）
转速3000~6000 RPM（可调）（根据环境温度自动调节）
风量≥50 CFM（立方英尺/分钟）（确保控制器内部温差≤10℃）
噪音<55 dB（A）（符合ISO 3741标准，适用于控制室环境）
寿命≥50,000小时（MTBF）（在25℃环境温度下连续运行）
2.3电气与安全认证
参数项详细说明
输入电压24 VDC（±10%）（与HIMA控制器供电兼容）
功率消耗<15W（单风扇）/<30W（双风扇全速）
防护等级IP20（室内安装，防手指接触）
安全认证ATEX Zone 2（Ex nA）、IECEx、UL/cUL（适用于全球危险区域）
3.功能特性详解
3.1智能温控与冗余控制
动态调速：内置温度传感器，根据控制器内部温度自动调整风扇转速（如40℃以下低速，60℃以上高速）。
故障切换：若主风扇故障，备用风扇立即启动，并通过HIMA诊断系统生成报警（如F 8627A控制器的“FAN_FAIL”信号）。
热插拔支持：可在系统运行状态下更换故障风扇，无需停机维护。
3.2防爆与环境适应性
防爆设计：外壳采用铝合金压铸，表面阳极氧化处理，防止静电积累；接口密封等级IP66（防尘防水）。
宽温运行：支持-20℃~+70℃环境温度（需配合加热模块用于极寒地区）。
抗振动：通过IEC 60068-2-64振动测试，适用于海上平台、振动设备附近安装。
3.3集成与诊断功能
LED状态指示：通过绿/黄/红三色LED显示风扇运行状态（如绿色=正常，红色=故障）。
通信接口：支持RS485（Modbus RTU）或HIMA专用协议，可将风扇状态上传至DCS/SIS系统。
历史记录：存储最近100条故障事件（包括时间戳、故障类型），便于追溯分析。
1.Product Positioning and Classification
The HIMA X-FAN 1803 is a fan module for HIMA safety control systems.It’s an optional accessory for the H41q/H51q series safety controllers,primarily used for heat dissipation and system redundancy.Its core functions include:
Active cooling:Provides forced air cooling for the controller’s internal electronic components(such as the CPU and communication modules),ensuring stable operation in high-temperature environments(such as those found in the chemical and oil and gas industries).
Redundancy:Can be combined with a backup fan module to achieve N+1 redundancy,preventing single points of failure from causing system downtime.
Environmental adaptability:Optimized for use in explosion-proof areas(Ex d/Ex i)or high-humidity/dust environments,it complies with international certifications such as ATEX and IECEx.2.Key Technical Specifications
2.1 Basic Specifications
Parameter Detailed Description
Applicable Systems:HIMA H41q/H51q Series Safety Controllers(such as the F8627A and F8650A models)
Dimensions:Standard 19-inch rack mount(1U height,width matching the controller)
Weight:Approximately 1.5 kg(including fan assembly and housing)
Connector:Dedicated connector(connects directly to the controller backplane,no additional cables required)
2.2 Fan Performance
Parameter Detailed Description
Number of Fans:Dual fan design(independently controlled,supports redundant switching)
Speed:3000-6000 RPM(adjustable)(automatically adjusts based on ambient temperature)
Airflow:≥50 CFM(cubic feet per minute)(ensure internal controller temperature gradient≤10°C)
Noise:<55 dB(A)(Complies with ISO 3741,suitable for control room environments)
Lifespan:≥50,000 hours(MTBF)(continuous operation at 25°C ambient temperature)
2.3 Electrical and Safety Certifications
Parameter Detailed Description
Input Voltage 24 VDC(±10%)(Compatible with HIMA controller power supplies)
Power Consumption<15W(single fan)/<30W(dual fans at full speed)
Protection Rating IP20(indoor installation,finger-safe)
Safety Certifications ATEX Zone 2(Ex nA),IECEx,UL/cUL(suitable for hazardous areas worldwide)
3.Features
3.1 Intelligent Temperature Control and Redundancy Control
Dynamic Speed Control:A built-in temperature sensor automatically adjusts fan speed based on the controller’s internal temperature(e.g.,low speed below 40°C,high speed above 60°C).
Failover:If the primary fan fails,the backup fan immediately starts up and generates an alarm via the HIMA diagnostic system(e.g.,”FAN_FAIL”signal on the F8627A controller).
Hot-Swap Support:Faulty fans can be replaced while the system is running,eliminating maintenance downtime.3.2 Explosion-Proof and Environmental Adaptability
Explosion-proof Design:The housing is made of die-cast aluminum alloy with an anodized surface to prevent static electricity accumulation;the interface sealing level is IP66(dustproof and waterproof).
Wide Operating Temperature:Supports ambient temperatures from-20°C to+70°C(requires a heating module for use in extremely cold regions).
Vibration Resistance:Passes IEC 60068-2-64 vibration testing,suitable for installation on offshore platforms and near vibrating equipment.
3.3 Integration and Diagnostic Functions
LED Status Indicator:A green/yellow/red LED displays the fan’s operating status(e.g.,green=normal,red=fault).
Communication Interface:Supports RS485(Modbus RTU)or HIMA proprietary protocol,enabling upload of fan status to a DCS/SIS system.
History Recorder:Stores the last 100 fault events(including timestamp and fault type)for easy traceability and analysis.
