描述
Honeywell 51308373-175 CC-TD0B11是一款数字输出模块，属于霍尼韦尔C300系列。以下是其产品详情：
基本参数
输入电压：24VDC。
输出通道数：16通道。
工作温度范围：-40℃至+85℃。
尺寸：140mm×105mm×30mm。
重量：约0.36kg。
电气特性
负载电压：最大15-30VDC。
输出电流：每通道绝对最大0.5A，每8通道4A（无短路条件），每模块6A（无短路条件）。
短路保护：单通道短路时，电流为0.5A；每8通道短路时，电流为3A（单短路）或1.5A（双短路）；模块短路时，电流为6A。
隔离电压：1500VAC rms或±1500VDC。
导通状态电压：典型值24V（负载电流0.5A时）。
关断状态电压：最大0V（无负载时，无负载条件下最大3.3V）。
关断状态漏电流：最大5.0μA。
开启/关闭时间：最大10ms。
功能特点
高可靠性：采用工业级设计和航空级材料，适用于各种恶劣的工业环境，能确保稳定运行。
易于集成：可以无缝集成到多种控制系统中，方便用户进行系统扩展和升级。
输出保护：具有独特的输出功率保护功能，当现场发生短路时，输出电路会检测到过流情况并关闭输出，仅影响单个通道，未短路的通道不受影响。
应用领域
主要用于工业自动化领域，如工厂自动化、过程控制、设备监控等，可用于控制和监控各种机械设备和过程控制系统中的信号扩展、放大、隔离和转换。
The Honeywell 51308373-175 CC-TD0B11 is a digital output module from the Honeywell C300 series.The following are product details:
Basic Parameters
Input Voltage:24 VDC.
Number of Output Channels:16 channels.
Operating Temperature Range:-40°C to+85°C.
Dimensions:140 mm×105 mm×30 mm.
Weight:Approximately 0.36 kg.
Electrical Characteristics
Load Voltage:Maximum 15-30 VDC.
Output Current:Absolute maximum 0.5 A per channel,4 A per 8 channels(no short circuit),6 A per module(no short circuit).
Short-Circuit Protection:0.5 A for a single channel short circuit;3 A(single short circuit)or 1.5 A(double short circuit)for a full 8 channels short circuit;6 A for a module short circuit.Isolation Voltage:1500VAC rms or±1500VDC.
On-State Voltage:Typical 24V(at 0.5A load current).
Off-State Voltage:Maximum 0V(at no load,maximum 3.3V under no-load conditions).
Off-State Leakage Current:Maximum 5.0μA.
Turn-On/Turn-Off Time:Maximum 10ms.
Features
High Reliability:Utilizing industrial-grade design and aerospace-grade materials,it is suitable for a variety of harsh industrial environments and ensures stable operation.
Easy Integration:It can be seamlessly integrated into a variety of control systems,facilitating system expansion and upgrades.
Output Protection:Featuring a unique output power protection function,when a short circuit occurs in the field,the output circuitry detects the overcurrent condition and shuts down the output,affecting only a single channel;unshorted channels remain unaffected.
Applications
Primarily used in industrial automation applications such as factory automation,process control,and equipment monitoring,it can be used for signal expansion,amplification,isolation,and conversion in the control and monitoring of various mechanical equipment and process control systems.
