描述
产品概述
HONEYWELL CC-TCF901是霍尼韦尔（Honeywell）推出的CF9控制防火墙输入/输出终端组件（IOTA），主要用于工业自动化系统的信号传输与网络安全防护。其核心功能包括物理连接、数据传输、电源分配及网络防火墙保护，适用于炼油、石化、化工、发电、钢铁等行业的过程控制场景。
技术参数
物理特性
尺寸：约12.1厘米×14.5厘米（长×宽）
重量：2公斤
安装方式：固定于C系列机柜的托架上，支持工业环境安装。
网络接口
以太网端口：9个RJ-45连接端口，支持高速数据传输与网络通信。
防火墙功能：集成高级防火墙模块，防止未授权访问和网络攻击。
电源与配电
供电电压：24 V直流电（24Vdc），为控制器及外部设备供电。
兼容性
控制系统：支持霍尼韦尔Experion LS、TDC 2000/3000、TPS、FSC等工业控制系统。
协议支持：兼容OPC、Modbus、EtherNet/IP等工业协议。
核心功能特点
信号传输与连接
多端口扩展：提供1个上行链路端口和8个独立FTE（Fieldbus Trunk Extension）配电电缆端口，支持控制器与现场设备的通信。
监控网络集成：第9个端口专用于FTE监控网络，实现对现场电缆状态的实时监控。
网络安全防护
防火墙机制：通过高级防火墙功能，过滤非法网络流量，保障控制系统安全。
冗余设计：支持冗余配置，确保单点故障不影响系统运行。
工业级可靠性
抗干扰能力：适应粉尘、高温（-25°C至+70°C）等恶劣环境，符合工业设备防护标准。
模块化维护：支持热插拔，便于快速更换故障模块。
灵活扩展性
混合控制支持：可与其他控制库函数无缝集成，无需系统升级即可扩展功能。
光纤兼容：支持通过光纤模块（如Ca-FSMx01、Ca-FMMx01）实现长距离通信。
典型应用场景
工业过程控制
石化反应釜的温度、压力实时监控与调节。
发电厂的锅炉燃烧控制与安全联锁系统。
自动化生产线
汽车制造中的机器人运动控制与设备状态监测。
制药行业的精确温湿度控制。
Product Overview
HONEYWELL CC-TCF901 is a CF9 control firewall input/output terminal component(IOTA)launched by Honeywell,which is mainly used for signal transmission and network security protection of industrial automation systems.Its core functions include physical connection,data transmission,power distribution and network firewall protection,and are suitable for process control scenarios in oil refining,petrochemical,chemical,power generation,steel and other industries.
Technical parameters
Physical characteristics
Size:about 12.1 cm x 14.5 cm(length x width)
Weight:2 kg
Installation method:Fixed to the bracket of C series cabinets and supports industrial environment installation.
Network interface
Ethernet port:9 RJ-45 connection ports,supporting high-speed data transmission and network communication.
Firewall Features:Integrate advanced firewall modules to prevent unauthorized access and cyber attacks.
Power and power distribution
Supply voltage:24 V DC(24 V dc),powering the controller and external equipment.
compatibility
Control system:Supports Honeywell Experion LS,TDC 2000/3000,TPS,FSC and other industrial control systems.
Protocol support:compatible with industrial protocols such as OPC,Modbus,EtherNet/IP.
Core functional features
Signal transmission and connection
Multi-port extension:Provides 1 uplink port and 8 independent FTE(Fieldbus Trunk Extension)distribution cable ports to support communication between the controller and field devices.
Monitoring network integration:The 9th port is dedicated to the FTE monitoring network,enabling real-time monitoring of on-site cable status.
Network security protection
Firewall mechanism:Through advanced firewall functions,illegal network traffic is filtered to ensure the security of the control system.
Redundant design:supports redundant configuration to ensure that a single point of failure does not affect the system operation.
Industrial-grade reliability
Anti-interference ability:adapts to harsh environments such as dust and high temperature(-25°C to+70°C),and complies with industrial equipment protection standards.
Modular maintenance:supports hot swapping,which facilitates quick replacement of faulty modules.
Flexible scalability
Hybrid control support:seamlessly integrates with other control library functions,extending functions without system upgrade.
Fiber compatibility:supports long-distance communication through fiber modules(such as Ca-FSMx01,Ca-FMMx01).
Typical application scenarios
Industrial process control
Real-time monitoring and regulation of the temperature and pressure of the petrochemical reactor.
Boiler combustion control and safety interlocking system in power plants.
Automated production line
Robot motion control and equipment status monitoring in automobile manufacturing.
Accurate temperature and humidity control in the pharmaceutical industry.
