描述
Honeywell MC-PAIH03 51304754是一款高性能的模拟量输入处理器模块，主要用于Honeywell过程控制系统中。以下是其产品详情：
基本信息
品牌：Honeywell
型号：MC-PAIH03
部件编号：51304754-150
产品类型：模拟量输入处理器
产地：美国
尺寸：30.73cm（长）x12.065cm（宽）x5.25cm（高）
重量：约0.6kg
电源：24VDC（±10%）
性能参数
输入通道：16个差分模拟输入通道
输入信号类型：支持电压、电流输入，可连接2线制或自供电变送器
输入范围：0-5V、1-5V、0.4-2V、4-20mA（通过250Ω）
A/D转换器分辨率：16位（使用14位）
输入扫描速率：每通道每秒4次采样，所有通道在250ms内完成采样
精度：在23.5°C±2°C时，满量程精度为±0.075%；在0-50°C时，满量程精度为±0.15%
隔离电压：通道间500Vrms，通道对地1000Vrms
功能特点
高精度采集：能够精确采集模拟信号，保证数据的准确性，精度可达±0.1%FS。
抗干扰能力强：具有70dB的共模抑制比（直流到60Hz，500Ω源不平衡）和32dB的常态抑制比（60Hz），输入和输出之间隔离，有效防止干扰。
灵活配置：可根据不同应用需求，灵活配置量程、滤波等参数。
支持冗余：支持双电源和冗余通信链路，提高系统的可靠性和可用性。
环境适应性强：工作温度范围为-40°C至+70°C，存储温度范围为-40°C至+85°C，湿度为5%至95%非冷凝，可在恶劣的工业环境中稳定运行。
Honeywell MC-PAIH03 51304754 is a high-performance analog input processor module,mainly used in Honeywell process control systems.The following are product details:
Basic Information
Brand:Honeywell
Model:MC-PAIH03
Part Number:51304754-150
Product Type:Analog Input Processor
Place of Manufacture:USA
Dimensions:30.73cm(L)x 12.065cm(W)x 5.25cm(H)
Weight:Approximately 0.6kg
Power Supply:24VDC(±10%)
Performance Parameters
Input Channels:16 differential analog input channels
Input Signal Type:Supports voltage and current inputs,and can connect to 2-wire or self-powered transmitters
Input Ranges:0-5V,1-5V,0.4-2V,4-20mA(through 250Ω)
A/D Converter Resolution:16 bits(14 bits used)
Input Scan Rate:4 samples per second per channel,all channels sampled within 250ms
Accuracy:±2°C at 23.5°C Full-scale accuracy is±0.075%at 0-50°C;±0.15%at 0-50°C.
Isolation voltage:500Vrms between channels,1000Vrms between channels and ground.
Features:
High-precision acquisition:Accurately acquires analog signals,ensuring data accuracy with an accuracy of up to±0.1%FS.
Strong anti-interference capability:70dB common-mode rejection ratio(DC to 60Hz,500Ωsource unbalanced)and 32dB normal-mode rejection ratio(60Hz).Input and output isolation effectively prevents interference.
Flexible configuration:Parameters such as range and filtering can be flexibly configured to meet different application requirements.
Redundancy support:Dual power supplies and redundant communication links are supported to improve system reliability and availability.Strong environmental adaptability:The operating temperature range is-40°C to+70°C,the storage temperature range is-40°C to+85°C,and the humidity is 5%to 95%non-condensing,allowing stable operation in harsh industrial environments.
