描述
产品概述
HYBRICON PCI354-1022-38是一款工业控制模块，属于PCI354系列，支持多种通信协议与电源管理功能。根据应用场景不同，该模块可作为模拟量输入模块或电源适配器使用，广泛应用于工业自动化、电力系统、医疗设备等领域。
技术参数
基础参数
结构形式：模块式
安装方式：控制室安装
工作电压：24V DC（逻辑电源）
环境温度：-40°C至+85°C
环境湿度：5%-95%（非冷凝）
重量：2.5KG
电气性能
输入/输出类型：
模拟量输入模块：支持多通道模拟信号采集（如温度、压力、流量等）。
电源适配器：提供稳定24V DC输出，兼容宽输入电压范围（如90-264V AC）。
通信接口：
RS232、RS485、TCP/IP、EtherNet/IP等工业协议。
支持TCP客户端模式，主动连接服务器并保持通信。
安全保护
过载保护：自动切断过载电流，防止设备损坏。
短路保护：内置保险丝或断路器，确保系统安全性。
过热保护：温度过高时自动降频或关机。
核心功能特点
模拟量输入模块功能
多协议支持：
TCP/UDP通信模式：支持主动连接服务器（TCP）或指定IP回应（UDP）。
虚拟串口管理：将网络数据重定向至虚拟串口，便于软件集成。
高精度信号处理：
支持12位或更高分辨率的模拟信号采集，确保数据准确性。
电源适配器功能
高效能源转换：
转换效率高达90%以上，优化能源利用。
宽输入电压范围（如90-264V AC），适应不同电网标准。
紧凑设计：
小巧轻便，适合空间受限的工业环境。
工业级可靠性
抗干扰设计：
通道隔离技术，防止电磁干扰（EMI）影响信号传输。
符合IEC/EN 61000电磁兼容标准。
冗余与容错：
支持热插拔，模块故障时可在线更换，减少停机时间。
Product Overview
HYBRICON PCI354-1022-38 is an industrial control module,belonging to the PCI354 series,supporting a variety of communication protocols and power management functions.Depending on the application scenario,this module can be used as an analog input module or a power adapter,and is widely used in industrial automation,power systems,medical equipment and other fields.
Technical parameters
Basic parameters
Structural form:modular
Installation method:Control room installation
Operating voltage:24V DC(logical power supply)
Ambient temperature:-40°C to+85°C
Ambient humidity:5%-95%(non-condensing)
Weight:2.5KG
Electrical performance
Input/Output Type:
Analog input module:supports multi-channel analog signal acquisition(such as temperature,pressure,flow,etc.).
Power adapter:Provides stable 24V DC output,compatible with wide input voltage ranges(such as 90-264V AC).
Communication interface:
Industrial protocols such as RS232,RS485,TCP/IP,EtherNet/IP.
Supports TCP client mode,actively connects to the server and maintains communication.
Safety protection
Overload protection:Automatically cut off the overload current to prevent damage to the equipment.
Short circuit protection:Built-in fuse or circuit breaker to ensure system safety.
Overheating protection:Automatically reduce frequency or shut down when the temperature is too high.
Core functional features
Analog input module function
Multi-protocol support:
TCP/UDP communication mode:Supports active connection to the server(TCP)or specified IP response(UDP).
Virtual serial port management:Redirect network data to the virtual serial port for easy software integration.
High-precision signal processing:
Supports analog signal acquisition at 12-bit or higher resolution to ensure data accuracy.
Power adapter function
Efficient energy conversion:
The conversion efficiency is as high as 90%,and energy utilization is optimized.
Wide input voltage range(such as 90-264V AC),adapting to different grid standards.
Compact design:
Small and lightweight,suitable for industrial environments where space is constrained.
Industrial-grade reliability
Anti-interference design:
Channel isolation technology prevents electromagnetic interference(EMI)from affecting signal transmission.
Comply with IEC/EN 61000 electromagnetic compatibility standards.
Redundancy and fault tolerance:
Supports hot swapping and can be replaced online when the module fails,reducing downtime.
