描述
ICS TRIPLEX T3419是一款数字输入模块，属于ICS Triplex公司Trusted系列产品，主要用于安全关键型应用。以下是其产品详情：
基本信息
品牌：ICS Triplex
型号：T3419
类型：数字输入模块
输入通道：40通道
输入电压范围：18至32V DC（标称24V DC）
电源：通过Trusted系统背板供电
尺寸：34x13x7cm
重量：0.66kg
工作温度范围：-5°C至60°C
存储温度范围：-25°C至70°C
工作湿度：5%至95%RH（非冷凝）
性能参数
输入电流：24V DC时每通道约4mA
导通状态电压：大于18V DC
关断状态电压：小于5V DC
导通状态电流：最小4mA
关断状态电流：最大1mA
通道隔离：各通道隔离，防止干扰或串扰
输入信号延迟：典型值1ms
诊断功能：具备全面诊断功能，包括检测输入卡住、输入超出范围等情况
自检间隔：定期自检以验证系统运行状况
输入保护：输入通道具有过压保护
功能特点
三重模块化冗余（TMR）架构：采用TMR技术，确保在硬件故障时仍能持续运行，具备故障检测和恢复能力。
热插拔功能：模块可在不关闭系统的情况下进行更换，便于维护。
高安全性：通过SIL3认证，适用于安全关键型应用。
The ICS TRIPLEX T3419 is a digital input module from ICS Triplex’s Trusted product line,designed for safety-critical applications.The following are product details:
Basic Information
Brand:ICS Triplex
Model:T3419
Type:Digital Input Module
Input Channels:40
Input Voltage Range:18 to 32V DC(Nominal 24V DC)
Power Supply:Powered via the Trusted System Backplane
Dimensions:34 x 13 x 7cm
Weight:0.66kg
Operating Temperature Range:-5°C to 60°C
Storage Temperature Range:-25°C to 70°C
Operating Humidity:5%to 95%RH(non-condensing)
Performance Parameters
Input Current:Approximately 4mA per channel at 24V DC
On-State Voltage:Greater than 18V DC
Off-State Voltage:Less than 5V DC
On-State Current:Minimum 4mA
Off-State Current:Maximum 1mA
Channel Isolation:Each channel is isolated to prevent interference or crosstalk
Input Signal Delay:Typical 1ms
Diagnostics:Comprehensive diagnostics,including detection of stuck inputs and out-of-range inputs.
Self-test interval:Periodic self-tests verify system health.
Input protection:Input channels feature overvoltage protection.
Features:Triple Modular Redundancy(TMR)architecture:Utilizes TMR technology to ensure continuous operation in the event of hardware failures,providing fault detection and recovery capabilities.
Hot-swappable capability:Modules can be replaced without shutting down the system,facilitating maintenance.
High safety:SIL3 certified,suitable for safety-critical applications.
