描述
ICS TRIPLEX T8110B是一款三重模块冗余（TMR）安全控制器。以下是其产品详情：
基本信息
品牌：ICS Triplex（现为Rockwell Automation旗下安全系统品牌）
型号：T8110B
类型：TMR安全控制器
供电电压：24V DC（±10%），典型功耗15W
尺寸：30.3cm×9.3cm×26.6cm
重量：2.94kg
性能参数
处理器：32位RISC处理器，主频≥100MHz
内存：用户程序内存为4MB Flash+2MB RAM，支持非易失性存储
I/O能力：最大I/O点数本地+远程扩展可达4096点（数字量/模拟量混合），支持TMR I/O，模块间通过光纤总线通信
通信接口：内置2×RS-485（Modbus RTU协议，主/从模式），1×以太网（10/100Mbps，支持Rockwell CIP Safety协议），扩展通信支持Profibus DP、Foundation Fieldbus（需附加模块）
安全与可靠性
安全认证：功能安全符合SIL 3（IEC 61508/IEC 61511），通过TÜV Rheinland认证
MTBF：≥50万小时
故障检测覆盖率：>99.9%
诊断功能：具备处理器/内存/通信通道在线自检，I/O模块断线、短路检测等功能，前面板LED可显示RUN/FAULT（绿/红）以及CHANNEL A/B/C等状态
编程与配置
编程平台：AADvance Studio（Rockwell专用工程软件）
编程语言：支持FBD（功能块图）、LD（梯形图）、ST（结构化文本）
安全逻辑库：预置SIL 3认证功能块
热备与在线维护：支持在线下载，程序更新无需停机，支持模块热插拔
The ICS TRIPLEX T8110B is a Triple Modular Redundant(TMR)safety controller.The following are product details:
Basic Information
Brand:ICS Triplex(now a safety system brand under Rockwell Automation)
Model:T8110B
Type:TMR safety controller
Power supply:24V DC(±10%),typical power consumption:15W
Dimensions:30.3cm×9.3cm×26.6cm
Weight:2.94kg
Performance Parameters
Processor:32-bit RISC processor,main frequency≥100MHz
Memory:User program memory:4MB Flash+2MB RAM,supports non-volatile storage
I/O Capacity:Maximum I/O points:4096(mixed digital/analog)with local and remote expansion.Supports TMR I/O.Inter-module communication is via a fiber optic bus.
Communication Interfaces:Built-in:2 x RS-485(Modbus RTU protocol,master/slave mode),1 x Ethernet(10/100Mbps,supports Rockwell CIP Safety protocol).Extended communication supports Profibus DP and Foundation Fieldbus(requires additional module)
Safety and Reliability
Safety Certification:Functional safety meets SIL 3(IEC 61508/IEC 61511),certified by TÜV Rheinland
MTBF:≥500,000 hours
Fault Detection Coverage:>99.9%
Diagnostic Features:Provides online self-test of the processor,memory,and communication channels,as well as I/O module disconnect and short-circuit detection.Front panel LEDs indicate RUN/FAULT(green/red)and CHANNEL A/B/C status.
Programming and Configuration
Programming Platform:AADvance Studio(Rockwell dedicated engineering software)
Programming Languages:Supports FBD(Function Block Diagram),LD(Ladder Diagram),and ST(Structured Text)
Safety Logic Library:Pre-installed SIL 3-certified function blocks
Hot Standby and Online Maintenance:Supports online downloads for program updates without downtime and hot-swappable modules.
